HIGH QUALITY PINCERS HOLDER CHUCKS, HIGH SPEED
1560GM
Product description as Art. 1560GH
MAS/BT ER PINCERS HOLDER CHUCKS
MAS/BT BT 40 shank, M16 internally threaded end.
Balancing level G 6.3 15000 rpm
Type
25
32
Tightening capacity Ø mm 2-16
2-20
Height D
mm 40
50
Height a
mm 55
55
Height E
mm 93
95
Height F
mm -
55
For pliers Art.
1561 GL
1561 GN
1560GM
Each 189,00
189,00
Chucks are supplied without locking collars and without seal rings.
For locking collars and rings see Art. 1560 GPA-B-C-E.
The E value refers to tools with shank < or = 16mm.
The F value refers to tools with shank > 16mm.
