453
Prices in EURO - VAT not included
6
453
SELF-CENTRING CHUCKS
1563T
new
Set of 3 external jaws in tempered steel, integral. For Art. 1563 P.
Ø
mm
80
100
125
160
200
250
315
1563T
Per series 110,00 127,00 133,00 152,00 162,00 201,00 329,00
vuoto
SELF-CENTRINGCHUCKS
1563V
new
Set of 3 jaws in untempered steel, integral. For Art. 1563 P.
Ø
mm
80
100
125
160
200
250
315
1563V
Per series 85,20 89,70 89,50 104,00 119,00 150,00 240,00
vuoto
SELF-CENTRINGCHUCKS
1565G
Prod. SCU - Röhm
Simple guide, special spheroidal die cast body. 3-jaws very high-precision model.
With 2 jaw sets: 1 for inside use, 1 for outside use and wrench. Slipping parts hardened and
ground. Excellent vibration absorption, crown forged, balanced and hardened. In compliance with
DIN 6350 standards.
Ø
mm
100
125
160
200
250
315
Bore Ø
mm 20
32
42
55
76
103
rev/min
Nr
4500
4000
3600
3000
2500
2000
Tightening force
kN 27
31
47
55
63
69
1565G
Each 903,00 992,00 1.140,00 1.380,00 1.950,00 2.690,00
On request we supply Jaws sets for indoor, outdoor and not hardened.
vuoto
Riferimenti quote
A (Diametro)
mm 100
125
160
200
250
315
B (H6) mm
mm 70
95
125
160
200
260
C
mm 3
4
4
4
5
5
D
mm 50
56
65
73,5
82
95
E
mm 20
32
42
55
76
103
F
mm 83
108
140
176
224
286
G
mm 3xM8 3xM8 3xM10 3xM10 3xM12 3xM16
H
mm 48
52
61
69
90
130
J
mm 18
22,5
26
32,5
40
46
K
mm 8
9
10
11
12
14
Peso c.a.
Kg 2,9
4,5
8,2
14,6
25,7
44,2
SELF-CENTRINGCHUCKS
1567P
new
J
C
G
A
F
D
E
L
B
B1
Prod. SCU
Single guide, special spheroidal die cast body.
4-jaws very high-precision model.
With 2 jaw sets: 1 for inside use, 1 for outside use and wrench. Slipping parts hardened and
ground. Excellent vibration absorption, forged crown, balanced and hardened. In compliance with
DIN 6350 standards.
Ø
mm
125
160
200
250
315
Bore Ø
mm 32
42
55
76
103
rev/min
Nr
4000
3600
3000
2500
2000
Tightening force
kN 24
31
37
46
55
1567P
Each 528,00 590,00 683,00 938,00 1.430,00
vuoto
A (Diametro)
mm 125
160
200
250
315
B
mm 56
64,5
75
85
94
B1
mm 60,8 69,3 79,8 88,8 99,1
C
mm 4
4
4
5
5
D H7
mm 95
125
160
200
260
E
mm 32
42
55
76
103
F
mm 108
140
176
224
286
G
mm 3xM8 6xM10 6xM10 6xM12 6xM16
J
mm 20
32
29
34
43
L
mm 40
43
45
53
57
Peso c.a.
Kg 5
10
17,5
29
50
Riferimenti quote
SELF-CENTRINGCHUCKS
1567R
new
Set of 4 internal jaws in tempered steel, integral. For Art. 1567 P.
Ø
mm
125
160
200
250
315
1567R
Per series 210,00 240,00 256,00 316,00 519,00
vuoto
SELF-CENTRINGCHUCKS
1567T
new
Set of 4 external jaws in tempered steel, integral. For Art. 1567 P.
Ø
mm
125
160
200
250
315
1567T
Per series 210,00 240,00 256,00 316,00 519,00
vuoto
