451
Prices in EURO - VAT not included
6
451
TRACTION COMPENSATED PINCERS
1562GPA
32
Prod. SCU
In special steel, finely worked. Traction compensation, male change on chuck directly, without
removing the pincer. Sealing ring to keep the male holder pivot clean and prevent seizing up. Ball
sliding and drawing.
Size 32.
Lunghezza corsa esp. 8mm. Dimensions (mm) D = 33 L = 48.
Tightening Ø
mm
3,5
4
4,5
6
7
8
9
1562GPA
Each 178,00 178,00 169,00 153,00 153,00 153,00 153,00
Tightening Ø
mm
10
11
1562GPA
Each 153,00 153,00
vuoto
TRACTIONCOMPENSATEDPINCERS
CNC CHUCK VICES
1562GRA
Prod. SCU
Suitable for DIN 2080, DIN 69871, BT and HSK-A chucks.
For assembly and disassembly operations of the tools on the toolholders.
Steel body with reversable locking device, for tenon assembly.
With safety pin to prevent chucks from accidentally falling. Base with 4 fixing holes for workbench
mounting.
Type
1
2
For drives
ISO 40/HSK-A63 ISO 50/HSK-A100
Height
mm
160
210
Width
mm
120
120
Overall length
mm
130
160
Bores width between centres mm
85
85
Bores length between centres mm
95
125
Weight
Kg
6,3
9,6
1562GRA
Each
312,00
350,00
vuoto
CNCCHUCKVICES
ZERO-SETTERS
1562GRE
Orig. MIB - Art. 01027091
Hardened special steel.
To set tools on "zero" and fix the chuck reference point in axial direction.
Reference height 50mm, mobile taster surface Ø 33,5mm, with dial indicator Ø 40mm, reading
0.01mm. Capacity mm 8. Zero-setter dimensions Ø 58mmx50 h.
1562GRE
Each 141,00
vuoto
ZERO-SETTERS
1562GRF
Orig. MIB - Art. 01027090
Magnetic type.
Hardened special steel.
To set tools on "zero" and fix the chuck reference point in axial direction.
Reference height 50mm, mobile taster surface Ø 25mm, with incorporated dial indicator Ø 40mm,
reading 0.01mm. Capacity mm 8. Zero-setter dimensions mm50x48x50 h.
1562GRF
Each 196,00
vuoto
ZERO-SETTERS
3-D TASTERS
1562S
IP67
Prod. SCU
High quality version "made in Germany". Precision ±0.01 mm.
Body made from sturdy, stable aluminium alloy. Shockproof head protection system with pre-set
breaking point. Cylindrical shank, Weldon type Ø 20mm. Body length with tracer bar 113mm,
shank length 50mm, body width 65mm., tracer bar ball Ø 4mm. Tracer bar length 25mm. Large
display with double-scale reading for side, front and vertical movements. With 2 adjustment screws
for zeroing. Can be installed horizontally and vertically on machine tools and electro-milling
systems. It is fixed to the tool holder chuck for easy and precise positioning of the chuck axes. This
makes it easy to determine the piece zero and the piece dimensions. It is possible to work on all
three axes and the indicator always moves in the same direction, measuring the distance from the
piece, without the need for additional calculations.
With IP 67 protection for temporary immersion in liquids and dust penetration.
1562S
Each 685,00
vuoto
Tasting bars for taster Art. 1562 S.
Ball Ø
mm
4
8
Overall length
mm 25
65
Type
standard optional
O1562S
Each 81,10
140,00
vuoto
3-DTASTERS
