948
Prices in EURO - VAT not included
948
WATER AND OIL TIGHT PRECISION DIAL INDICATORS
11
WATER AND OIL TIGHT PRECISION DIAL INDICATORS
4409GB
1/100
Prod. SCU - Orig. Käfer
DIN 878. 1/100 graduations. With 2 hands for millimetres and cents of millimetres. With tolerance
markers. Stem and contact point in stainless steel. Zerosetting by dial rotation. Water-tight and
shock-proof, metal case; stem protected for applications with liquids.
Measuring capacity
mm 10
Dial Ø
mm 61,5
Drive Ø
mm 8 h 6
Each pointer revolution
mm 1
4409GB
Each 211,00
vuoto
WATERANDOILTIGHTPRECISIONDIAL INDICATORS
TOLERANCE DIAL INDICATORS
4410GB
1/100
Prod. SCU - Orig. Käfer
DIN 878. 1/100 graduations. Indicated for checking tolerance.
With 1 hand.
Shock-proof metal case.
Measuring capacity
mm 0,8
Dial Ø
mm 58
Drive Ø
mm 8 h 6
Position excursion on piece mm 9
Bilateral reading scales
mm ±0,45
4410GB
Each 131,00
vuoto
TOLERANCEDIAL INDICATORS
DIAL DEPTH GAUGES
4411GB
1/100
Prod. SCU - Orig. Käfer
1/100 graduations. With 2 hands. With high precision base.
Screw clamping for perfect fastening of dial gauges.
Measuring capacity
mm 30
Dial Ø
mm 58
Each pointer revolution
mm 1
Base dimensions
mm 80x16
4411GB
Each 380,00
vuoto
Only base apt for Art. 4411 GB.
O4411G
Each 126,00
vuoto
DIALDEPTHGAUGES
DIAL TEST INDICATORS, SWIVEL CONTACT POINT
4412GC
1/100
Prod. SCU - Orig. Käfer
Dial Ø 28mm, stem Ø 8mm x h 6, 1/100 graduations.
Travel 0.8mm, for tolerance ±0.4mm right-left with lateral movement.
Swivel range of contact point 220°. To be mounted on articulated holder Art. 4412 GS.
Rod with contact point, length 12.3mm.
4412GC
Each 175,00
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
4412GF
1/100
High precision model, with dial Ø 40mm, 1/100 graduations.
Stem Ø 8mm x h 6, inserted from above, travel 0.8mm, for tolerance ±0.4mm forward-backward
with front movement.
Swivel range of stylus in hard metal 240°.
To be mounted on articulated holder Art. 4412 GS and arch centering Art. 4412 GT by joint Art.
O4412 GM 4 or 8.
Rod with contact point, length 12mm.
4412GF
Each 175,00
For drive Ø 4 mm see Art. O4412 GM 4.
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
4412GL
1/100
High precision model, with dial Ø 40mm, 1/100 graduations.
Stem Ø 8mm x h 6, inserted from above, travel 0.5mm, for tolerance ±0.25mm forward-backward
with front movement.
Swivel range of stylus in hard metal 240°.
To be mounted on articulated holder Art. 4412 GS and arch centering Art. 4412 GT by joint Art.
O4412 GM 4 or 8.
Extended rod with contact point, length 35mm.
4412GL
Each 243,00
For drive Ø 4 mm see. Art. O4412 GM 4.
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
