951
Prices in EURO - VAT not included
951
CENTESIMAL ELECTRONIC DIGITAL DIAL INDICATORS
11
4420GM
1/100
Orig. MIB - Art. 02031023
Precision model. 1/100 graduations.
Dial display with 4 big digits for easy reading.
mm/inch selection button. Zerosetting button for relative and incremental measurements. On/off
button. Contact in hard metal. Battery power supply 1.5 V.
Precision: 30 µm.
Measuring capacity
mm 50
Drive Ø
8 h 6
4420GM
Each 298,00
vuoto
CENTESIMALELECTRONICDIGITALDIAL INDICATORS
MILLESIMALI ELECTRONIC DIGITAL DIAL INDICATORS
4420GS
1/1000
Orig. MIB - Art. 02031029
Precision model. 1/100 graduations.
Dial display with 4 big digits, easy to read.
mm/inch selection button. Zerosetting button for relative and incremental measurements. On/off
button. Contact in hard metal. Powered by a 3 V lithium battery ecological, long life.
Precision 0.01 mm. Dial diameter 57mm.
Precision 5 µm.
Measuring capacity
mm 12,5
Drive Ø
8 h 6
4420GS
Each 288,00
vuoto
MILLESIMALIELECTRONICDIGITALDIAL INDICATORS
INDICATOR STANDS
4421
Orig. MIB - Art. 06070000
Universal type with sliding column on base.
For comparators with coupling Ø 8mm.
Ground parallel surfaces and chrome finished support rods.
The horizontal arm swivels and tilts.
Total height 270mm. Column diameter 14mm. Horizontal arm length 235mm, diameter 12mm.
Base dimensions: length 220mm, width 58mm, height 35mm.
Without dial indicator.
4421
Each 86,10
vuoto
INDICATORSTANDS
4421A
Prod. SCU - Orig. Käfer
Magentic model. Small dimensions, handy and easy to use. Flat base with 2 permanent active
magnetics.
Base dimensions: length 73mm, width 38mm, height 11mm. Horizontal arm, 360° swiveling and
30° vertically tilting approx.
Total height 46m. Length of swivel arm up to holder opening 35mm. Holder opening for dial
indicators Ø 8mm.
Without dial indicator.
Magnet force
N 180
4421A
Each 84,90
For similar model, but with prism-shaped base see Art. 4414 GS.
vuoto
INDICATORSTANDS
4421B
Orig. MIB - Art. 06071010
Magnetic type. Standard machining, prismatic base.
Magnetic adhesion with lever insertion and detachment.
Base dimensions: length 60mm, width 50mm, height 55mm.
The horizontal arm swivels and tilts, with micrometer adjustment.
Total height 231mm. Column diameter 12mm.
Horizontal arm length 150mm, diameter 10mm.
For comparators with coupling Ø 8mm.
Without dial indicator.
Magnet force
N 600
4421B
Each 34,50
vuoto
INDICATORSTANDS
