960
Prices in EURO - VAT not included
960
REVOLUTION COUNTERS
11
REVOLUTION COUNTERS
4437GD
4437GS
Prod. SCU - Orig. IVO
Electric SUBTRACTING system.
To preset the desired value, push the lateral lever backwards and hold it in this position. Push the
button to select the desired value. Then release the lever.
The counters subtracts from the preset value, until it reaches zero, when the electric contact
disengages the counter. The electric contact may operate a relay, an alarm, a light or the three
simultaneously, close or far.
To repeat the same value, just push the lever. The counter can be connected both on the right and
on the left.
The lever can be mounted both on the right and on the left. 1 rev. = 1 unit.
For alternate current up to V 220.
Art......................................
4437GD 4437GS
Rotation
right
left
Ciphers height
mm 7
7
No. of ciphers
5
5
Max speed
rev/min 6000
6000
Base dimensions
mm 142x88
142x88
Each 927,00 1.120,00
vuoto
REVOLUTIONCOUNTERS
4438GD
4438GS
Prod. SCU
Electrical ADDITIONING system.
Quick zero-setting by means of lever. Body in die-cast aluminium, sturdy construction. Upon
reach of the preset value, a micro commuter is activated according to basic operation settings.
Digit number 5. Digit height 8mm. 1 rev. = 1 unit. Max. speed 5000 rpm.
Dimensions 130x87x57mm.
Contact range 1 A 24 V d.c.
Art......................................
4438GD 4438GS
Rotation
right
left
Each 416,00
416,00
vuoto
REVOLUTIONCOUNTERS
STROKE COUNTERS
4440G 1
4440G 2
4440G 3
4440G 4
Prod. SCU - Orig. IVO
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Lever travel: min. 38°, max. 60°.
Max number of strokes: approx. 500 per min.
The lever can be adjusted in any postion of the shaft.
knob for instantaneous zerosetting. Number of digits 5.
Digits height 4.5mm. Base dimensions 29x60mm.
Art......................................
4440G 1 4440G 2 4440G 3 4440G 4
Shaft side
right
right
left
left
Rotation
right
left
right
left
Each 91,20
91,20
91,20
91,20
vuoto
STROKECOUNTERS
4440GE 1
4440GE 2
4440GE 3
4440GE 4
Prod. SCU
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Max number of strokes: approx. 1000 per min.
The lever can be adjusted in any postion of the shaft.
Knurled knob for instantaneous zero-setting. Body and cover in synthetic material.
Digit number 6. Digit height 5mm. Dimensions 46.5x33x31mm.
Art......................................
4440GE 1 4440GE 2 4440GE 3 4440GE 4
Shaft side
right
right
left
left
Rotation
right
left
right
left
Each 56,50
56,50
56,50
56,50
vuoto
Available on request mounting bases.
STROKECOUNTERS
