961
Prices in EURO - VAT not included
961
STROKE COUNTERS
11
4441GD 1
4441GD 2
4441GS 1
4441GS 2
Prod. SCU - Orig. IVO
Removable key for zerosetting.
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Lever travel: min. 38°, max. 60°.
Max number of strokes: approx. 500 per min.
The lever can be adjusted in any postion of the shaft.
Knob for instantaneous zerosetting.
Art......................................
4441GD 1 4441GD 2 4441GS 1 4441GS 2
Rotation
right
right
left
left
Ciphers height
mm 4,5
7
4,5
7
No. of ciphers
6
7
6
7
Wheels Ø
mm 4
7
4
7
Base dimensions
mm 60x70
120x64
60x70
120x64
Each 126,00
192,00
126,00
192,00
vuoto
STROKECOUNTERS
4442GD 1
4442GD 2
4442GS 1
4442GS 2
Movable lever for instantaneous zerosetting.
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Lever travel: min. 38°, max. 60°.
Max number of strokes: approx. 500 per min.
The lever can be adjusted in any postion of the shaft.
Knob for instantaneous zerosetting.
Art......................................
4442GD 1 4442GD 2 4442GS 1 4442GS 2
Rotation
right
right
left
left
Ciphers height
mm 4,5
7
4,5
7
No. of ciphers
5
5
5
5
Base dimensions
mm 80x48
120x64
80x48
120x64
Each 158,00
258,00
158,00
258,00
vuoto
STROKECOUNTERS
4443GD 1
4443GS 1
Prod. SCU
Quick zero-setting through upper lever.
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Max. stroke number approx 700 per min. Body in aluminium zama, sturdy construction.
Digit number 5. Digit height 6mm. Dimensions 93x47x32mm.
Art......................................
4443GD 1 4443GS 1
Rotation
right
left
Each 126,00
126,00
vuoto
STROKECOUNTERS
METER COUNTERS
4443GT
Prod. SCU
Electric SUBTRACTING system.
Body in die-cast aluminium, metal internal workings and self-lubricating synthetic material, speed
1000 strokes per min.
Right shaft side, right rotation.
Digit number 4. Digit height 8mm. Dimensions 115x95x50mm.
Contact range 1 AMP 24V d.c.
4443GT
Each 162,00
vuoto
METERCOUNTERS
METER COUNTERS
4444GD
4444GS
Prod. SCU - Orig. IVO
Adds in one direction. Subtracts in the opposite direction. 5 rev. = 1 metre.
For wheels circumfurence 200mm.
Max speed 200 metre per min.
Zerosetting by means of movable lever.
Counts up to 9999.9 metres. Shaft diameter 4mm.
Digits height 4.5mm. Base dimensions 80x48mm.
Right shaft rotation, without wheel.
4444GD
Each 158,00
vuoto
Product description as Art. 4444GD
Left shaft rotation, without wheel.
4444GS
Each 158,00
For wheels see Art. 4452 GA-B-C
vuoto
METERCOUNTERS
