DRILLS FOR METALS, RIGHT-HAND ROTATION
1117
13
Prices in EURO - VAT not included
Ø
mm
8,6 8,7 8,8 8,9
9
9,1 9,2 9,3 9,4*
9,5 9,6 9,7 9,8 9,9*
10
Overall length
mm 84
84
84
84
84
84
84
84
84
84
89
89
89
89
89
Helix length
mm 40
40
40
40
40
40
40
40
40
40
43
43
43
43
43
8312G
Each 32,30 36,10 38,10 41,90 16,40 40,90 40,90 46,70 45,70 17,80 43,80 43,30 44,30 36,40 20,70
Ø
mm
10,5 11 11,5 12 12,5 13
14
15
Overall length
mm 89
95
95 102 102 102 107 111
Helix length
mm 43
47
47
51
51
51
54
56
8312G
Each 37,50 38,50 46,20 51,10 53,90 57,70 63,50 75,10
Up to Ø 7.5mm in 10pcs packing units. * Sizes running out of stock.
vuoto
DRILLSFORMETALS,RIGHT-HANDROTATION
DRILLS FOR STAINLESS STEEL AND ALLOYS, RIGHT-HAND ROTATION
8315G
INOX
HSS-E
Orig. Hartner - Art. 81173
DIN 1897, Inox-Drill. COBALT HSS-E. Cutting angle 130°.
EXTRA-SHORT pattern.
Particular drill geometry with special spiral flute and web shape for easier chip ejection. For
stainless steel V2A and V4A, Titanium, Aluminium and some copper alloys.
Cylindrical shank.
Ø
mm
1
1,1 1,2*
1,3 1,4 1,5 1,6 1,7*
1,8 1,9*
2
2,1 2,2 2,3 2,4
Overall length
mm 26
28
30
30
32
32
34
34
36
36
38
38
40
40
43
Helix length
mm 6
7
8
8
9
9
10
10
11
11
12
12
13
13
14
8315G
Each 10,20 9,28 9,58 9,90 9,90 9,08 8,76 7,64 8,14 7,30 6,70 10,50 9,28 9,28 9,70
Ø
mm
2,5 2,6 2,7 2,8 2,9*
3
3,1*
3,2 3,3 3,4 3,5 3,6 3,8 3,9*
4
Overall length
mm 43
43
46
46
46
46
49
49
49
52
52
52
55
55
55
Helix length
mm 14
14
16
16
16
16
18
18
18
20
20
20
22
22
22
8315G
Each 7,22 9,70 13,10 10,20 8,72 9,08 8,72 9,70 10,80 10,40 10,20 13,50 10,90 8,24 9,48
Ø
mm
4,1 4,2 4,3 4,4*
4,5 4,6*
4,8 4,9
5
5,1 5,2 5,3*
5,5 5,6*
5,7
Overall length
mm 55
55
58
58
58
58
62
62
62
62
62
62
66
66
66
Helix length
mm 22
22
24
24
24
24
26
26
26
26
26
26
28
28
28
8315G
Each 11,60 11,40 12,10 9,70 10,90 11,20 12,80 15,60 11,10 16,80 20,60 23,20 16,20 20,60 24,30
Ø
mm
5,8 5,9
6
6,1 6,2*
6,3 6,4*
6,5 6,6 6,7 6,8 6,9
7
7,1 7,2*
Overall length
mm 66
66
66
70
70
70
70
70
70
70
74
74
74
74
74
Helix length
mm 28
28
28
31
31
31
31
31
31
31
34
34
34
34
34
8315G
Each 27,90 28,90 14,60 30,40 21,80 34,10 24,10 16,80 36,10 37,10 34,10 34,60 21,70 39,70 27,80
Ø
mm
7,4 7,5 7,6 7,7*
7,8 7,9
8
8,1 8,2*
8,3*
8,4*
8,5 8,7 8,8*
9
Overall length
mm 74
74
79
79
79
79
79
79
79
79
79
79
84
84
84
Helix length
mm 34
34
37
37
37
37
37
37
37
37
37
37
40
40
40
8315G
Each 41,30 22,70 42,80 32,20 46,40 63,90 19,80 45,90 44,20 39,30 40,40 25,30 60,90 44,20 30,40
Ø
mm
9,2 9,3*
9,4 9,5 9,6*
9,8*
10 10,2 10,5 10,6*
11*
11,5
Overall length
mm 84
84
84
84
89
89
89
89
89
89
95
95
Helix length
mm 40
40
40
40
43
43
43
43
43
43
47
47
8315G
Each 63,90 51,20 67,10 27,90 51,20 52,90 31,50 59,80 65,10 81,80 58,90 79,40
Up to Ø 7.5mm in 10pcs packing units. * Sizes running out of stock.
vuoto
DRILLSFORSTAINLESSSTEELANDALLOYS,RIGHT-HANDROTATION
DRILLS FOR METALS, RIGHT-HAND ROTATION
8325G
HSS
TIN
Orig. Hartner - Art. 84400
DIN 1897. Type N. HSS+TIN. Cutting angle 118°.
EXTRA-SHORT pattern.
Sharpening according to DIN 1414, Form N.
For alloy steel up to R 900 N/sqmm, cast iron, spheroidal cast iron, aluminium and short-chip
aluminium alloys, bronze and electrolitic copper.
Cylindrical shank. TIN treatment.
Ø
mm
2
2,5
3
3,5
4
4,5
5
5,5
6
6,5
7
7,5
8
8,5
9
Overall length
mm 38
43
46
52
55
58
62
66
66
70
74
74
79
79
84
Helix length
mm 12
14
16
20
22
24
26
28
28
31
34
34
37
37
40
8325G
Each 9,30 9,86 9,86 10,30 10,30 10,80 11,20 12,40 12,40 22,10 23,30 25,50 24,40 28,30 27,20
Ø
mm
9,5
10 10,5 11 11,5 12 12,5 13 13,5 14 14,5 15 15,5 16
17
Overall length
mm 84
89
89
95
95 102 102 102 107 107 111 111 115 115 119
Helix length
mm 40
43
43
47
47
51
51
51
54
54
56
56
58
58
60
8325G
Each 34,40 29,90 42,10 42,10 46,10 49,30 47,50 51,50 59,80 57,60 62,10 64,20 61,50 69,80 80,80
Ø
mm
17,5 18
20
Overall length
mm 123 123 131
Helix length
mm 62
62
66
8325G
Each 80,80 79,70 94,10
Up to Ø 7.5mm in 10pcs packing units. - Sizes mm 12,5 and 15,5 running out of stock.
