DRILLS FOR METALS, RIGHT AND LEFT-HAND ROTATION
1121
13
Prices in EURO - VAT not included
Ø
mm
2,8 2,9
3
3,1 3,2 3,25 3,3 3,4 3,5 3,6*
3,7 3,75 3,9
4
4,1 4,2
Overall length
mm 61 61 61 65 65 65 65 70 70 70 70 70 75 75 75 75
Helix length
mm 33 33 33 36 36 36 36 39 39 39 39 39 43 43 43 43
8402G
Each 5,38 5,58 3,80 5,96 4,48 7,12 5,20 6,44 4,42 6,74 6,54 8,94 7,12 4,52 6,54 6,06
Ø
mm
4,25 4,3 4,4 4,5 4,6 4,7 4,75 4,8 4,9
5
5,1 5,2 5,25 5,3 5,4*
5,5
Overall length
mm 75 80 80 80 80 80 80 86 86 86 86 86 86 86 93 93
Helix length
mm 43 47 47 47 47 47 47 52 52 52 52 52 52 52 57 57
8402G
Each 9,62 7,88 8,18 6,26 9,04 8,18 16,20 8,36 8,94 5,38 8,94 9,24 22,60 9,72 7,68 7,80
Ø
mm
5,6 5,7*
5,75 5,8 5,9*
6
6,2 6,25 6,4*
6,5 6,6 6,7 6,75 6,8 6,9
7
Overall length
mm 93 93 93 93 93 93 101 101 101 101 101 101 109 109 109 109
Helix length
mm 57 57 57 57 57 57 63 63 63 63 63 63 69 69 69 69
8402G
Each 10,80 9,42 23,60 11,10 12,70 7,50 12,40 24,60 8,80 8,94 13,80 13,50 13,10 12,50 14,10 9,90
Ø
mm
7,1 7,2*
7,25 7,3 7,4 7,5 7,6 7,7 7,75 7,8 7,9
8 8,1*
8,2* 8,25*
8,3
Overall length
mm 109 109 109 109 109 109 117 117 117 117 117 117 117 117 117 117
Helix length
mm 69 69 69 69 69 69 75 75 75 75 75 75 75 75 75 75
8402G
Each 13,50 9,42 31,30 14,50 14,80 12,50 16,90 17,60 32,30 18,10 18,10 13,10 14,40 17,70 27,70 20,20
Ø
mm
8,4 8,5 8,6*
8,7 8,75*
8,8 8,9
9
9,1 9,2*
9,3*
9,4 9,5 9,6 9,7 9,75
Overall length
mm 117 117 125 125 125 125 125 125 125 125 125 125 125 133 133 133
Helix length
mm 75 75 81 81 81 81 81 81 81 81 81 81 81 87 87 87
8402G
Each 21,20 13,90 17,10 22,20 11,40 24,60 23,60 17,30 28,40 19,80 20,50 29,40 17,50 30,80 30,80 53,90
Ø
mm
9,8 9,9 10 10,1 10,2 10,25* 10,4* 10,5 10,6* 10,75* 10,8* 10,9 11 11,1 11,25 11,6*
Overall length
mm 133 133 133 133 133 133 133 133 133 142 142 142 142 142 142 142
Helix length
mm 87 87 87 87 87 87 87 87 87 94 94 94 94 94 94 94
8402G
Each 29,90 32,70 20,70 34,70 29,90 32,80 26,20 25,50 26,70 34,90 29,20 38,10 30,80 40,40 51,10 36,40
Ø
mm
11,75 11,8* 11,9*
12 12,75* 13,5* 14*
15 15,5* 16* 16,5*
17 17,5* 18* 18,5* 19*
Overall length
mm 142 142 151 151 151 160 160 169 178 178 184 184 191 191 198 198
Helix length
mm 94 94 101 101 101 108 108 114 120 120 125 125 130 130 135 135
8402G
Each 47,20 36,90 36,90 32,70 54,30 38,90 40,50 62,50 55,30 52,30 76,80 114,00 89,10 94,20 102,00 110,00
Ø
mm
20*
Overall length
mm 205
Helix length
mm 140
8402G
Each 133,00
Up to Ø 7.5mm in 10pcs packing units. * Sizes running out of stock.
vuoto
DRILLSFORMETALS,RIGHTAND LEFT-HANDROTATION
ASSORTMENTS OF DRILL TIPS
8410G
HSS
Orig. Hartner - Art. 88012 / 0,015
Assortments in steel plate wallet.
With HSS cylindrical drills Art. 8400 G.
Complete assortment.
With tips by
mm 1 to 5,9
Quantity of tips
50
Progression
mm 0.1
8410G
Each 158,00
vuoto
EMPTY CONTAINERS FOR ASSORTMENTS.
In steel plate.
For Art. 8410 G.
O8410G
Each 26,10
vuoto
ASSORTMENTSOFDRILLTIPS
8412G
HSS
Orig. Hartner - Art. 88012 / 0,013
Assortments in steel plate wallet.
With HSS cylindrical drills Art. 8400 G.
Complete assortment.
With tips by
mm 1 to 10
Quantity of tips
19
Progression
mm 0.5
8412G
Each 96,70
vuoto
EMPTY CONTAINERS FOR ASSORTMENTS.
In steel plate.
For Art. 8412 G.
O8412G
Each 14,50
