ASSORTMENTS OF DRILL TIPS
1122
13
Prices in EURO - VAT not included
8414G
HSS
Orig. Hartner - Art. 88012 / 0,016
Assortments in steel plate wallet.
With HSS cylindrical drills Art. 8400 G.
Complete assortment.
With tips by
mm 6 to 10
Quantity of tips
41
Progression
mm 0.1
8414G
Each 333,00
vuoto
EMPTY CONTAINERS FOR ASSORTMENTS.
In steel plate.
For Art. 8414 G.
O8414G
Each 54,40
vuoto
ASSORTMENTSOFDRILLTIPS
8416G
HSS
Orig. Hartner - Art. 88012 / 0,014
Assortments in steel plate wallet.
With HSS cylindrical drills Art. 8400 G.
Complete assortment.
With tips by
mm 1 to 13
Quantity of tips
25
Progression
mm 0.5
8416G
Each 216,00
vuoto
EMPTY CONTAINERS FOR ASSORTMENTS.
In steel plate.
For Art. 8416 G.
O8416G
Each 19,10
vuoto
ASSORTMENTSOFDRILLTIPS
DRILLS FOR METALS, RIGHT-HAND ROTATION
8423G
HSS
Orig. Hartner - Art. 81040
DIN 338. Type FN. HSS. Cutting angle 130°. SHORT pattern.
Thinned cutting edge according to DIN 1412 A. Special drills for deep holes.
Suitable for automatic machines.
For steel up to R 1000 N/sqmm.
Cylindrical shank.
Ø
mm
2
2,1 2,2 2,4*
2,5 2,6 2,7 2,8 2,9
3
3,1 3,15 3,2 3,3 3,4 3,5
Overall length
mm 49 49 53 57 57 57 61 61 61 61 65 65 65 65 70 70
Helix length
mm 24 24 27 30 30 30 33 33 33 33 36 36 36 36 39 39
8423G
Each 5,08 5,76 5,76 5,50 5,08 5,98 6,32 6,44 6,32 5,30 6,54 8,24 6,32 6,54 7,00 5,76
Ø
mm
3,6 3,8 3,9
4
4,1 4,2 4,3 4,4 4,5 4,6 4,7 4,8 4,9*
5
5,2 5,3
Overall length
mm 70 75 75 75 75 75 80 80 80 80 80 86 86 86 86 86
Helix length
mm 39 43 43 43 43 43 47 47 47 47 47 52 52 52 52 52
8423G
Each 7,44 7,56 8,24 6,32 7,90 7,22 8,24 8,46 7,44 9,82 8,92 8,92 7,46 7,90 9,70 10,80
Ø
mm
5,4*
5,5 5,6*
5,7 5,8 5,9
6
6,1 6,2 6,3 6,4 6,5 6,6*
6,7 6,8
7
Overall length
mm 93 93 93 93 93 93 93 101 101 101 101 101 101 101 109 109
Helix length
mm 57 57 57 57 57 57 57 63 63 63 63 63 63 63 69 69
8423G
Each 9,24 9,36 9,58 10,60 10,90 12,30 10,40 12,60 12,20 12,60 13,30 11,30 11,20 13,80 13,50 11,80
Ø
mm
7,2*
7,3 7,4 7,5 7,6*
7,7*
7,8*
7,9*
8*
8,1 8,2*
8,3*
8,4 8,5 8,6 8,7*
Overall length
mm 109 109 109 109 117 117 117 117 117 117 117 117 117 117 125 125
Helix length
mm 69 69 69 69 75 75 75 75 75 75 75 75 75 75 81 81
8423G
Each 15,80 21,50 19,40 14,80 17,20 17,20 19,20 21,10 15,40 23,70 21,70 23,50 28,80 17,20 28,80 23,70
Ø
mm
8,8 8,9
9 9,1*
9,2 9,3 9,4 9,5 9,6 9,7 9,8 9,9 10 10,5 10,8 11
Overall length
mm 125 125 125 125 125 125 125 125 133 133 133 133 133 133 142 142
Helix length
mm 81 81 81 81 81 81 81 81 87 87 87 87 87 87 94 94
8423G
Each 30,50 32,70 18,20 31,40 32,70 32,70 36,10 23,20 34,40 40,60 36,70 37,80 20,20 32,20 50,80 35,10
Ø
mm
11,2 11,5 12 12,2 12,5*
13
Overall length
mm 142 142 151 151 151 151
Helix length
mm 94 94 101 101 101 101
8423G
Each 67,70 38,40 44,10 85,70 41,40 57,50
Up to Ø 7.5mm in 10pcs packing units. - * Sizes running out of stock.
