1186 / 1378
1186
COUNTERSINKS
1186
13
Prices in EURO - VAT not included
8854G
90
HSS-E
Orig. Dürr - Art. 217-41
Single flute, ground.
COBALT HSS-E.
For countersinking holes in iron and steel.
60° HEAD TAPER. Morse taper shank.
Countersink max Ø
mm
30
40
50
Drive
C.M.
2
3
3
For bores Ø
mm 3-30
3-40
3-50
Overall length
mm 114
150
152
8854G
Each 105,00 160,00 253,00
COUNTERSINKS
COUNTERSINKS WITH INTERCHANGEABLE TOOL BITS
8856G
90
HARTMETALL
TIN
Orig. Dürr - Art. 217-00
2 flutes, with HARDMETAL interchangeable tool bits, TIN-coating for high-quality performance
and time saving, no need for resharpening. Particularly suitable for use with CNC. For
countersinking high-resistance steel.
90° HEAD TAPER - DIN 74 shape A fine. Cylindrical shank with clamping flat DIN 1835B.
Supplied without tool bits.
Countersink max Ø
mm
19
23
26
30
34
37
Countersink min Ø
mm 7
11
11
12
16
19
Cylindrical drive Ø
mm 16
16
16
20
20
20
Overall length
mm 100
100
100
100
100
100
To countersink
M.
10
12
14
16
18
20
8856G
Each 289,00 297,00 308,00 321,00 331,00 334,00
vuoto
Interchangeable tool bits for Art. 8856 G x 19 - 23.
O8856GA
Each 52,50
Interchangeable tool bits for Art. 8856 G x 26.
O8856GB
Each 55,20
Interchangeable tool bits for Art. 8856 G x 30-34-37.
O8856GC
Each 63,10
Spare screws TORX T 8 (M 2.6x5) for Art. 8856 G x 19-23-26.
O8856GF
Each 5,78
Spare screws TORX T 10 (M 3.5x6) for Art. 8856 G x 30-34-37.
O8856GL
Each 5,78
COUNTERSINKSWITH INTERCHANGEABLETOOLBITS
COUNTERSINKS
8858G
60
HSS
Orig. Dürr - Art. 216-21
Multiple flutes, HSS ground.
For countersinking holes in cast iron.
Not equally spaced flutes for better finishing.
60° HEAD TAPER -DIN 334. Cylindrical shank.
Countersink max Ø
mm
6
8
10 12,5 16
20
25 31,5
Countersink min Ø
mm 1
1,5
1,8
2
3,2
5
7
9
Drive Ø
mm 6
8
8
8
10
10
12
16
Cutting edges
No
3
5
5
5
7
7
9
9
Overall length
mm 50
50
50
50
60
63
75
90
8858G
Each 18,20 18,20 28,50 30,60 41,10 49,60 68,70 75,10
COUNTERSINKS
8860G
60
HSS
Orig. Dürr - Art. 216-51
Multiple flutes, HSS ground.
For countersinking holes in cast iron.
Not equally spaced flutes for better finishing.
60° HEAD TAPER -DIN 334. Morse taper shank.
Countersink max Ø
mm
16
25 31,5 40
50
63
80
Countersink min Ø
mm 3,2
7
9
12
16
20
25
Drive
C.M.
1
2
2
3
3
4
4
Cutting edges
No
7
9
9
11
13
15
17
Overall length
mm 100 125 132 160 170 200 215
8860G
Each 58,60 104,00 130,00 197,00 297,00 480,00 990,00
Size mm16 running out of stock.
COUNTERSINKS
8862G
90
HSS
Orig. Dürr - Art. 217-21
Multiple flutes, HSS ground.
For countersinking holes in cast iron.
Not equally spaced flutes for better finishing.
90° HEAD TAPER -DIN 335. Cylindrical shank.
Countersink max Ø
mm
6
8
10 12,5 16
20
25 31,5
Countersink min Ø
mm 1
1,5
1,8
2
3,2
5
7
9
Drive Ø
mm 6
8
8
8
10
10
12
16
Cutting edges
No
3
5
5
5
7
7
9
9
Overall length
mm 48
48
48
48
56
60
70
80
8862G
Each 13,60 13,60 20,40 24,40 33,90 41,10 56,40 73,90
COUNTERSINKS
