COUNTERSINKS
1182
13
Prices in EURO - VAT not included
8822GL
90
HSS-E
Three flutes, ground.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER – DIN 335. Morse taper shank.
In COBALT HSS-E.
Countersink max Ø
mm
31
37
40
50
63
80
Countersink min Ø
mm 4,2
4,8
10
14
16
22
Drive
C.M.
2
2
3
3
4
4
Overall length
mm 112 118 140 150 180 190
8822GL
Each 145,00 172,00 215,00 267,00 435,00 739,00
vuoto
COUNTERSINKS
8823G
90
HSS-E
Orig. Dürr - Art. 217-51
With 5 ground flutes.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER - DIN 335. Morse taper shank.
COBALT HSS-E. For very high resistance steel, such as TITANIUM and its alloys, INCONEL and
similar materials.
Countersink max Ø
mm
31
40
50
63
Countersink min Ø
mm 6
10
14
16
Drive
C.M.
2
3
3
4
Overall length
mm 111
140
150
180
8823G
Each 369,00 457,00 593,00 717,00
vuoto
COUNTERSINKS
8824G
90
HARTMETALL
Orig. Dürr - Art. 217-53
Three flutes, ground.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER – DIN 335. Morse taper shank.
CARBIDE-TIPPED flutes. For steel and materials difficult to chip,cast iron, aluminium-silicium
alloys and stainless steel.
Countersink max Ø
mm
20,5 25
31
37
40
50
63
80
Countersink min Ø
mm 7
9
10
12
14
18
22
28
Drive
C.M.
2
2
2
2
3
3
4
4
Overall length
mm 100 103 108 115 137 147 179 187
8824G
Each 254,00 283,00 312,00 387,00 403,00 502,00 622,00 806,00
vuoto
COUNTERSINKS
8824GE
90
HARTMETALL
Orig. Dürr - Art. 217-63
With 5 ground flutes.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER - DIN 335. Morse taper shank.
HARDMETAL flutes (size 31mm only, with hard metal head). For very high resistant steel and
materials, such as TITANIUM and its alloys, manganese, hardened steel up to 60 HRC, INCONEL
and similar materials.
Countersink max Ø
mm
31
40
50
63
Countersink min Ø
mm 6
14
18
22
Drive
C.M.
2
3
3
4
Overall length
mm 108 137 147 179
8824GE
Each 748,00 783,00 938,00 1.180,00
vuoto
COUNTERSINKS
8825G
100
HSS
Orig. Dürr - Art. 217-31
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
100° HEAD TAPER. Cylindrical shank.
Countersink max Ø
mm
6,3
8
10,4
12,4
16,5
20,5
25
Countersink min Ø
mm 1,5
2
2,5
2,8
3,2
3,5
3,8
Drive Ø
mm 5
6
6
8
10
10
10
Overall length
mm 44
49
49
55
59
62
65
8825G
Each 20,20 22,60 25,20 28,50 38,30 56,70 63,10
vuoto
COUNTERSINKS
8826G
120
HSS
Orig. Dürr - Art. 217 - 31
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
120° HEAD TAPER. Cylindrical shank.
Countersink max Ø
mm
6,3
8
12,5
14,4
16
20
25
Countersink min Ø
mm 1,5
2
2,8
2
3,2
3,5
3,8
Drive Ø
mm 5
6
8
8
10
10
10
Overall length
mm 44
49
54
57
57
59
63
8826G
Each 20,20 22,60 28,50 37,00 38,30 56,70 63,10
