1200 / 1378
1200
COUNTERSINKS FOR 90° COUNTERSINK-HEAD SCREW SEATS (PASSING-THROUGH SCREWS)
1200
13
Prices in EURO - VAT not included
8932G
HSS
Orig. Dürr - Art. 212-11 / 212-21
HSS - DIN 1866.
For creating the seat to the 90° countersink head of passing-through screws.
For iron and high-resistance steel.
Cylindrical shank. FINE tolerance.
For screws
M.
2
2,5
3
4
5
6
8
Cutting edges Ø
mm 4,3
5
6
8
10 11,5 15
Guide Ø
mm 2,2
2,7
3,2
4,3
5,3
6,4
8,4
Drive Ø
mm 4,3
5
5
5
8
8
12,5
Overall length
mm 56
56
71
71
80
80
100
8932G
Each 55,60 50,10 48,20 53,30 57,40 70,40 98,10
vuoto
COUNTERSINKSFOR 90°COUNTERSINK-HEADSCREWSEATS (PASSING-THROUGHSCREWS)
COUNTERSINKS FOR 90° COUNTERSINK-HEAD SCREW SEATS (SCREWS TO THREAD)
8934G
HSS
Orig. Dürr - Art. 212-21
HSS - DIN 1866.
For creating the seat to the 90° countersink head of screws to thread.
For iron and high-resistance steel.
Cylindrical shank. FINE tolerance.
For screws
M.
3
4
5
6
8
Cutting edges Ø
mm 6
8
10
11,5
15
Guide Ø
mm 2,5
3,3
4,2
5
6,8
Drive Ø
mm 5
5
8
8
12,5
Overall length
mm 71
71
80
80
100
8934G
Each 53,70 59,20 63,10 79,60 98,10
vuoto
COUNTERSINKSFOR 90°COUNTERSINK-HEADSCREWSEATS (SCREWSTO THREAD)
JET REAMERS
8940G
Prod. SCU
In hardened steel. Ground cutting edges.
For soft metal, iron, steel up to R 80/90 Kg.
Size
75
74
72
71
70
68
66
65
64
62
60
58
56
55
53
Max Ø
mm 0,5 0,55 0,6 0,65 0,7 0,75 0,8 0,85 0,9 0,95
1
1,1 1,2 1,3 1,5
Useful length
mm 35
35
40
40
40
40
40
45
48
48
55
55
55
55
60
8940G
Each 1,40 1,40 1,36 1,36 1,36 1,36 1,36 1,36 1,36 1,36 1,36 1,40 1,40 1,50 1,78
Size
52
50
48
46
39
31
28
21
15
8
6
5
4
3
2
Max Ø
mm 1,6 1,7 1,9
2
2,5
3
3,5
4
4,5
5
6
7
8
9
10
Useful length
mm 60
70
70
70
75
80
85
90
95 100 110 110 125 130 130
8940G
Each 1,78 1,84 2,46 2,46 3,10 3,70 4,98 6,76 7,90 9,26 12,40 15,10 19,20 24,70 32,10
vuoto
JETREAMERS
8942G
For nozzle grinding and reboring.
Set of 12 jet reamers Art. 8940 G Size 72-71-70-66-65-64-60-58-55-53-50-48 with reamer holder.
In wallet.
8942G
Each 27,10
vuoto
JETREAMERS
JET REAMERS WITH HANDLE
8944G
Prod. SCU
For nozzle grinding and reboring.
Pentagonal operating part with knurled plastic handle.
Size
78
75
72
70
66
64
60
Max Ø
mm 0,4
0,5
0,6
0,7
0,8
0,9
1
8944G
Each 2,12
1,92
1,88
1,88
1,88
1,88
1,88
Size
56
54
51
46
Max Ø
mm 1,2
1,4
1,7
2
8944G
Each 1,96
2,26
2,80
3,14
vuoto
JETREAMERSWITHHANDLE
8946G
For nozzle grinding and reboring.
Set of 12 jet reamers Art. 8944 G Size 78-72-66-60-56-54.
In plastic bag.
8946G
Each 16,60
vuoto
JETREAMERSWITHHANDLE
