MACHINE TAPER PIN REAMERS
1202
13
Prices in EURO - VAT not included
MACHINE TAPER PIN REAMERS
8968G
HSS
Orig. Dürr - Art. 324-31
HSS – DIN 2179.
Ground, helicoidal, 45° left-hand cutting edges.
Taper 1:50. Cylindrical shank.
Tolerance H7.
Rated Ø
mm
2 2,5 3
4
5
6 6,5 8 10 12
Min Ø
mm 1,9 2,4 2,9 3,9 4,9 5,9 6,4 7,9 9,9 11,8
Max Ø
mm 2,86 3,36 4,06 5,26 6,36 8 8,78 10,8 13,4 16
Cutting edge length
mm 48 48 58 68 73 105 119 145 175 210
Overall length
mm 86 86 100 112 122 160 188 207 245 290
Drive Ø
mm 3,15 3,15 4
5 6,3 8 8,5 10 12,5 16
8968G
Each 46,10 54,30 46,10 49,40 52,70 59,20 77,30 90,50 116,00 140,00
Size mm 6,5 running out of stock.
vuoto
MACHINETAPERPINREAMERS
MACHINE REAMERS
8970G
HSS-E
Orig. Dürr - Art. 314-21
COBALT HSS-E – DIN 212.
Ground helicoidal cutting edges. Left-hand spiral flute. For right-hand cutting.
Cylindrical shank. Tolerance H7. Long pattern.
Ø
mm
1,5 1,8*
2
2,2*
2,5 2,8*
3
3,2*
3,5
4
4,5
5
5,5
6
6,5
Cutting edge length
mm 8
10
11
12
14
15
15
16
18
19
21
23
26
26
28
Overall length
mm 40
46
49
53
57
61
61
65
70
75
80
86
93
93 101
Drive Ø
mm 1,5 1,8
2
2,2 2,5 2,8
3
3,2 3,5
4
4,5
5
5,6 5,6 6,3
8970G
Each 27,30 33,80 25,50 33,80 25,50 33,80 24,50 33,80 27,30 26,40 27,30 27,30 32,60 27,30 34,70
Ø
mm
7
7,5
8
8,5
9
9,5
10 10,5 11 11,5 12
13
14
15
16
Cutting edge length
mm 31
31
33
33
36
36
38
38
41
41
44
44
47
50
52
Overall length
mm 109 109 117 117 125 125 133 142 142 142 151 151 160 162 170
Drive Ø
mm 7,1 7,1
8
8
9
9
10
10
10
10
10
10 12,5 12,5 12,5
8970G
Each 34,70 37,50 35,70 44,30 41,50 49,20 41,50 59,70 59,70 73,20 59,70 68,90 69,90 73,20 75,10
Ø
mm
17
18
19
20
Cutting edge length
mm 54
56
58
60
Overall length
mm 175 182 189 195
Drive Ø
mm 14
14
16
16
8970G
Each 91,50 93,50 110,00 101,00
* Sizes running out of stock.
vuoto
MACHINEREAMERS
8971G
HSS-E
COBALT HSS-E – DIN 212.
Ground helicoidal cutting edges. Left-hand spiral flute. For right-hand cutting.
Cylindrical shank. Tolerance H7.
Type
2
3
4
5
6
6L
8
Ø
mm 2
3
4
5
6
6
8
Cutting edge length
mm 11
15
19
23
26
26
33
Max boring length
mm 45
65
70
80
90
210
115
Drive Ø
mm 2
3
4
5
6
6
8
8971G
Each 90,50 69,10 70,80 72,40 75,70 178,00 79,10
Type
8L
10
10L
12
Ø
mm 8
10
10
12
Cutting edge length
mm 33
38
38
44
Max boring length
mm 200
140
200
160
Drive Ø
mm 8
10
10
12
8971G
Each 181,00 90,50 185,00 101,00
vuoto
MACHINEREAMERS
8971R
HARTMETALL
Prod. SCU
SOLID CARBIDE K 10 - DIN 212.
Ground, helicoidal cutting edges. Left-hand spiral flute. For right-hand cutting. Cylindrical shank.
Tolerance H7.
Ø
mm
2
2.5
3
3.5
4
4.5
5
Cutting edge length
mm 11
14
15
18
19
21
23
Overall length
mm 50
57
60
70
75
80
93
Drive Ø
mm 2
2.5
3
3.5
4
4.5
5
8971R
Each 24,70 22,50 24,70 28,50 32,10 37,10 43,20
Ø
mm
5.5
6
6.5
7
8
9
10
Cutting edge length
mm 26
26
28
31
33
36
38
Overall length
mm 93
93
100
109
117
125
135
Drive Ø
mm 5.5
6
6.5
7
8
9
10
8971R
Each 49,50 50,80 57,80 65,50 77,10 88,50 110,00
Ø
mm
11
12
13
Cutting edge length
mm 41
44
44
Overall length
mm 140
150
150
Drive Ø
mm 11
12
13
8971R
Each 140,00 166,00 193,00
