REAMER HOLDERS
1201
13
Prices in EURO - VAT not included
REAMER HOLDERS
8948G
Prod. SCU
Plastic handle. Steel clamps.
Overall length
mm
100
110
115
160
170
Opening
mm 0-1,2 1,2-2
2-3
3-4,5
4-6
For reamers 8940 G
Gr
75 to 56 55 to 46 39 to 21 15 to 8 6 e 5
8948G
Each 8,22
9,98 10,20 26,80 34,30
REAMERHOLDERS
8950G
Brass body. Steel clamps.
With 2 interchangeable jaws.
Overall length
mm
100
110
111
Opening
mm 0-2,6 0-3,2
0-4
For reamers 8940 G
Gr
75 to 31 75 to 15 75 to 6
8950G
Each 20,80 23,10 23,10
REAMERHOLDERS
HAND TAPER PIN REAMERS
8954G
HSS
Orig. Dürr - Art. 323-21
HSS – DIN 9. Helical, ground cutting edges.
Taper 1:50. With drive board and cylindrical tang.
Tolerance H7.
Rated Ø
mm
1,5
2
2,5
3
4
5
6
8
10
12
16
20
25
Min Ø
mm 1,4
1,9
2,4
2,9
3,9
4,9
5,9
7,9
9,9
11,8
15,8
19,8
24,7
Max Ø
mm 2,14
2,86
3,36
4,06
5,26
6,36
8
10,8
13,4
16
20,4
24,8
30,7
Cutting edge length
mm 37
48
48
58
68
73
105
145
175
210
230
250
300
Overall length
mm 57
68
68
80
93
100
135
180
215
255
280
310
370
Square drive
mm 2,5
2,5
2,5
3,15
4
5
6,3
8
10
11,2
14
18
22,4
8954G
Each 47,70 47,70 47,70 44,40 46,10 47,70 57,60 87,20 125,00 160,00 222,00 288,00 500,00
HANDTAPERPINREAMERS
TAPER REAMERS
8960G
HSS
Orig. Dürr - Art. 323-21
HSS. Helicoidal cutting edges. Taper 1:10.
With drive board and cylindrical tang.
Min/max Ø
mm
3/10
5/15 10/25 15/35
Cutting edge length
mm 70
100
150
200
Overall length
mm 100
140
195
250
Square drive
mm 6,3
10
16
22,4
8960G
Each 79,10 111,00 231,00 484,00
TAPERREAMERS
HAND REAMERS WITH CYLINDRICAL SHANK
8964
HSS
Prod. SCU
HSS – DIN 206B.
Ground helicoidal cutting edges.
With drive board and cylindrical shank.
Tolerance H7.
Ø
mm
5 5,5 6 6,5 7 7,5 8 8,5 9 9,5 10 10,5 11 11,5 12 12,5 13
Cutting edge length
mm 44 47 47 50 54 54 58 58 62 62 66 66 71 71 76 76 76
Overall length
mm 87 93 93 100 107 107 115 115 124 124 133 133 142 142 152 152 152
Square drive
mm 4 4,5 4,5 5 5,6 5,6 6,3 7,1 7,1 7,1 8
9
9
10 10 10 10
8964
Each 21,10 28,40 22,70 32,50 25,50 33,30 27,70 35,40 30,50 36,60 32,90 39,70 44,20 43,60 48,50 56,50 52,90
Ø
mm
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 30
Cutting edge length
mm 81 81 87 87 93 93 100 100 107 107 115 115 115 124 124 124
Overall length
mm 163 163 177 177 188 188 201 201 215 215 231 231 231 247 247 247
Square drive
mm 11,2 11,2 12,5 12,5 14 14 16 16 18 18 20 20 20 22,4 22,4 22,4
8964
Each 59,30 64,70 72,80 74,10 75,10 78,80 92,80 93,30 102,00 110,00 128,00 129,00 143,00 154,00 171,00 188,00
HANDREAMERSWITHCYLINDRICALSHANK
8965G
HSS
Orig. Dürr - Art. 313-21
HSS – DIN 206B.
Ground helicoidal cutting edges (1.5 – 1.6 – 1.8mm with straight cutting edges).
With drive board and cylindrical shank.
Tolerance H7.
Ø
mm
1,5* 1,6* 1,8*
2 2,2*
2,5 2,8 3 3,5 4 4,5 5 5,5 6
7
8
9
Cutting edge length
mm 20 21 23 25 27 29 31 31 35 38 41 44 47 47 54 58 62
Overall length
mm 41 44 47 50 54 58 62 62 71 76 81 87 93 93 107 115 124
Square drive
mm 1,12 1,25 1,4 1,6 1,8 2 2,24 2,24 2,8 3,15 3,55 4 4,5 4,5 5,6 6,3 7,1
8965G
Each 43,50 43,10 43,10 37,20 45,10 37,20 48,40 37,20 43,50 37,20 41,80 39,10 44,30 37,90 40,70 42,10 46,70
Ø
mm
10 11 12 13 14 15 16 17 18 19 20 22 24 25 26*
28 30
Cutting edge length
mm 66 71 76 76 81 81 87 87 93 93 100 107 115 115 115 124 124
Overall length
mm 133 142 152 152 163 163 175 175 188 188 201 215 231 231 231 247 247
Square drive
mm 8
9 10 10 11,2 11,2 12,5 12,5 14 14 16 18 20 20 20 22,4 22,4
8965G
Each 46,70 55,10 56,10 80,50 89,50 93,60 96,60 108,00 111,00 122,00 121,00 147,00 169,00 171,00 180,00 248,00 236,00
* Sizes running out of stock.
