MACHINE SHELL REAMERS
1209
13
Prices in EURO - VAT not included
MACHINE SHELL REAMERS
9000G
HSS-E
Orig. Dürr - Art. 314-81
COBALT HSS-E – DIN 219.
Shank hole, taper 1:30 – Right-hand cutting. Tolerance H7.
Helicoidal cutting edges.
Ø
mm
25
26
27
28
30
32
34
35
Cutting edge length
mm 32
32
32
32
32
36
36
36
Drive bore Ø
mm 13
13
13
13
13
16
16
16
Overall length
mm 45
45
45
45
45
50
50
50
9000G
Each 176,00 183,00 219,00 191,00 185,00 231,00 227,00 224,00
Ø
mm
36
38
40
42
45
47
48
50
Cutting edge length
mm 40
40
40
40
45
45
45
45
Drive bore Ø
mm 19
19
19
19
22
22
22
22
Overall length
mm 56
56
56
56
63
63
63
63
9000G
Each 262,00 259,00 254,00 250,00 346,00 341,00 334,00 329,00
Ø
mm
52
55
58
60
65
70
75
80
Cutting edge length
mm 50
50
50
50
56
56
63
63
Drive bore Ø
mm 27
27
27
27
32
32
40
40
Overall length
mm 71
71
71
71
80
80
90
90
9000G
Each 436,00 421,00 495,00 443,00 606,00 673,00 905,00 1.040,00
vuoto
MACHINESHELLREAMERS
9003G
HSS-E
Orig. Dürr - Art. 314-91
Product description as Art. 9000G
45° helicoidal cutting edges.
Ø
mm
25
26
27
28
30
32
34
35
Cutting edge length
mm 32
32
32
32
32
36
36
36
Drive bore Ø
mm 13
13
13
13
13
16
16
16
Overall length
mm 45
45
45
45
45
50
50
50
9003G
Each 255,00 255,00 255,00 250,00 241,00 285,00 275,00 270,00
Ø
mm
36
38
40
42
45
47
48
50
Cutting edge length
mm 40
40
40
40
45
45
45
45
Drive bore Ø
mm 19
19
19
19
22
22
22
22
Overall length
mm 56
56
56
56
63
63
63
63
9003G
Each 356,00 347,00 338,00 328,00 482,00 474,00 468,00 458,00
Ø
mm
52
55
58
60
65
70
75
80
Cutting edge length
mm 50
50
50
50
56
56
63
63
Drive bore Ø
mm 27
27
27
27
32
32
40
40
Overall length
mm 71
71
71
71
80
80
90
90
9003G
Each 650,00 642,00 625,00 616,00 788,00 750,00 972,00 1.080,00
vuoto
MACHINESHELLREAMERS
9010G
Orig. Dürr - Art. 289
CONICAL SHANKS FOR REAMERS ART. 9000 G – 9003 G
Manufactured according to DIN 217.
Conical reaming on the shaft 1:30.
Morse taper shank.
Rated Ø
mm
13
16
19
22
27
32
40
For reamers 9000G e
9003G
mm 25-30 32-35 36-42 45-50 52-60 65-70 75-80
Overall length
mm 250
261
298
312
359
376
396
Drive
C.M.
3
3
4
4
5
5
5
9010G
Each 133,00 147,00 172,00 193,00 284,00 347,00 431,00
vuoto
MACHINESHELLREAMERS
EXPANDING HAND REAMERS
9013
HSS
Prod. SCU
Small expansion model – DIN 859.
HSS. Hand use.
Ground, helicoidal cutting edges.
With drive board and cylindrical shank.
Ø
mm
5
6
7
8
9
10
11
12
Cutting edge length
mm 30
33
38
42
46
50
51
56
Overall length
mm 87
93
107 115 124 133 142 152
Square drive
mm 4
4,5
5,6
6,3
7,1
8
9
10
Expansion
mm 0,1
0,1
0,1
0,1
0,1
0,1 0,15 0,15
9013
Each 57,20 68,50 77,60 86,90 95,90 101,00 115,00 124,00
Ø
mm
13
14
15
16
17
18
19
20
Cutting edge length
mm 56
61
61
67
67
68
68
75
Overall length
mm 152 163 163 177 177 188 188 201
Square drive
mm 10 11,2 11,2 12,5 12,5 14
14
16
Expansion
mm 0,15 0,15 0,15 0,2
0,2
0,2
0,2
0,2
9013
Each 142,00 151,00 165,00 187,00 210,00 219,00 240,00 240,00
vuoto
EXPANDINGHANDREAMERS
