1210 / 1378
1210
EXPANDING HAND REAMERS
1210
13
Prices in EURO - VAT not included
9016G
HSS
Orig. Dürr - Art. 317-21
Small expansion model – DIN 859.
HSS. Hand use.
Helicoidal cutting edges.
With drive board and cylindrical shank.
The max expansion capacity is equal to 1% of the indicated Ø.
Ø
mm
6
8
9
10
12
13
14
15
Cutting edge length
mm 33
42
46
50
56
56
61
61
Overall length
mm 93
115 124 133 152 152 163 163
Square drive
mm 4,5
6,3
7,1
8
10
10 11,2 11,2
9016G
Each 83,90 104,00 113,00 112,00 130,00 160,00 153,00 158,00
Ø
mm
16
18
19
20
22
24
25
30
Cutting edge length
mm 67
68
68
75
82
85
85
94
Overall length
mm 175 188 188 201 215 231 231 247
Square drive
mm 12,5 14
14
16
18
20
20 22,4
9016G
Each 196,00 208,00 211,00 221,00 265,00 295,00 290,00 377,00
Size mm 9 running out of stock.
EXPANDINGHANDREAMERS
ADJUSTABLE REAMERS
9020
Prod. SCU
With SHORT blades, parallel expansion.
Cutting edges in special steel (90 Mn Cr V – AISI 02), ground. Hand use.
With drive board and cylindrical shank.
Expansion
mm
8-9
9-10
10-11 11-12 12-13,5 13,5-15,5 15,5-18 18-21 21-24 24-27,5 27,5-31,5 31,5-37
Cutting edges length
mm 38
40
46
48
50
55
66
66
77
88
88
106
Overall length
mm 110
120
125
130
140
155
170
180
200
225
235
277
Blades
No
4
4
4
4
5
5
5
5
5
5
5
5
9020
Each 92,20 94,60 94,60 95,90 98,70 106,00 116,00 124,00 139,00 157,00 192,00 240,00
Expansion
mm
37-45 45-55 55-65
Cutting edges length
mm 106
130
130
Overall length
mm 290
320
350
Blades
No
5
6
6
9020
Each 353,00 500,00 631,00
Spare blade for Art. 9020.
Expansion
mm
8-9
9-10 10-11 11-12 12-13,5 13,5-15,5 15,5-18 18-21 21-24 24-27,5 27,5-31,5 31,5-37
O9020
Per set
51,50 56,80 58,40 58,40 69,50 71,20 75,50 79,10 80,70 89,30 103,00 123,00
Expansion
mm
37-45 45-55 55-65
O9020
Per set 185,00 243,00 279,00
ADJUSTABLEREAMERS
9023
With LONG blades, parallel expansion.
Cutting edges in special steel (90 Mn Cr V – AISI 02), ground. Hand use.
With drive board and cylindrical shank.
Expansion
mm
10,5-12 12-13,5 13,5-15,5 15,5-17,5 17,5-19,5 19,5-21,5 21,5-24,5 27,5-31,5 31,5-37 37-45 45-55 55-65
Cutting edges length
mm 64
70
82
92
100
112
122
142
152
167
182
182
Overall length
mm 170
180
200
220
235
245
265
315
335
375
425
425
Blades
No
5
5
5
5
5
5
5
5
5
5
6
6
9023
Each 152,00 159,00 177,00 197,00 202,00 212,00 227,00 291,00 356,00 479,00 608,00 694,00
Product running out of stock.
Spare blade for Art. 9023.
Expansion
mm
10,5-12 12-13,5 13,5-15,5 15,5-17,5 17,5-19,5 19,5-21,5 21,5-24,5 24,5-27,5 27,5-31,5 31,5-37 37-45 45-55 55-65
O9023
Per set 91,10 94,40 97,10 101,00 103,00 107,00 119,00 127,00 156,00 178,00 233,00 292,00 342,00
Product running out of stock.
ADJUSTABLEREAMERS
9025
With SHORT blades and centring conical bush.
For combined or deep holes.
Cutting edges in special steel (90 Mn Cr V – AISI 02), ground. Hand use.
With drive board and cylindrical shank.
Expansion
mm
11-12 12-13,5 13,5-15,5 15,5-18 18-21 21-24 24-27,5 27,5-31,5 31,5-37 37-45 45-55
Cutting edges length
mm 48
50
55
66
66
77
88
88
106
106
130
Overall length
mm 208
230
265
310
340
365
405
425
475
500
560
Blades
No
5
5
5
5
5
5
5
5
5
5
6
9025
Each 156,00 167,00 170,00 180,00 201,00 211,00 231,00 278,00 360,00 534,00 719,00
Product running out of stock.
Spare blade for Art. 9025.
Expansion
mm
10-11 11-12 12-13,5 13,5-15,5 15,5-18 18-21 21-24 24-27,5 27,5-31,5 31,5-37 37-45 45-55 55-65
O9025
Per set
58,40 58,40 69,50 71,20 75,50 79,10 80,70 89,30 103,00 123,00 185,00 243,00 279,00
Product running out of stock.
ADJUSTABLEREAMERS
