1213 / 1378
1213
HAND TAPS
1213
13
Prices in EURO - VAT not included
HAND TAPS
9092L
M
HSSG
Orig. Völkel - Art. 670
Double-threaded type. Buster on one side and finisher on the other. Axial hexagonal hole on both
sides for use with Allen wrenches or ratched and internal hexagonal sockets. Hexagonal body for
use also with open end wrenches.
HSSG.
Right-hand use.
METRIC ISO THREAD - According to DIN 13 (DIN 357).
Ø
mm
11
12
14
16
18
20
22
Pitch
mm 1.5
1.75
2
2
2.5
2.5
2.5
Overall length
mm 70
70
70
70
80
80
80
Thread length
mm 22
22
22
22
24
24
24
Body hexagon
mm 8
8
10
10
13
13
15
Bore hexagon
mm 4
4
4
4
5
6
6
9092L
Each 20,40 20,40 23,30 26,90 29,10 32,10 40,70
Ø
mm
24
27
30
33
36
39
42
Pitch
mm 3
3
3.5
3.5
4
4
4.5
Overall length
mm 90
90
90
100
100
110
110
Thread length
mm 27
27
27
29
29
32
27
Body hexagon
mm 15
19
19
24
24
27
27
Bore hexagon
mm 8
8
10
10
10
12
12
9092L
Each 47,90 74,10 96,40 128,00 154,00 199,00 225,00
HANDTAPS
9092P
MF
HSSG
Orig. Völkel - Art. 677
Product description as Art. 9092L
METRIC ISO FINE THREAD - According to DIN 13 (DIN 2181).
Ø
mm
12
12
12
14
14
14
16
Pitch
mm 1
1,25
1,5
1
1,25
1,5
1
Overall length
mm 70
70
70
70
70
70
70
Thread length
mm 22
22
22
22
22
22
22
Body hexagon
mm 8
8
8
10
10
10
12
Bore hexagon
mm 4
4
4
4
4
4
4
9092P
Each 23,10 23,10 21,20 35,20 26,70 23,10 39,20
Ø
mm
16
18
18
18
20
22
22
Pitch
mm 1,5
1
1,5
2
1,5
1,5
2
Overall length
mm 70
80
80
80
80
80
80
Thread length
mm 22
24
24
24
24
24
24
Body hexagon
mm 12
13
13
13
15
17
17
Bore hexagon
mm 4
5
5
5
6
6
6
9092P
Each 28,20 42,40 32,10 42,40 39,20 55,20 55,20
Ø
mm
24
24
26
27
30
33
36
Pitch
mm 1,5
2
1,5
2
2
2
3
Overall length
mm 90
90
90
90
90
100
100
Thread length
mm 27
27
27
27
27
29
29
Body hexagon
mm 19
17
19
19
24
24
27
Bore hexagon
mm 8
8
8
8
10
10
10
9092P
Each 56,10 74,10 109,00 128,00 151,00 183,00 194,00
vuoto
HANDTAPS
9092R
BSP
HSSG
Orig. Völkel - Art. 678
Product description as Art. 9092L
CYLINDRICAL GAS THREAD G (BSP) -According to DIN ISO 228-1 (DIN 5157).
Ø
inches
1/4
3/8
1/2
3/4
1
1.1/4 1.1/2
2
Threads per inch
No 19
19
14
14
11
11
11
11
Overall length
mm 70
70
80
90
100 110 140 160
Thread length
mm 22
22
24
27
29
27
42
47
Body hexagon
mm 8
12
15
19
24
32
36
41
Bore hexagon
mm 4
4
6
8
10
12
17
19
9092R
Each 17,50 23,80 32,10 47,90 81,30 141,00 186,00 384,00
vuoto
HANDTAPS
HSS-CO 5% STANDARD TAPS
9093
M
HSSG
Orig. Völkel - Art. 67020
Contents:
1 pcs. per size, taps Art. 9092 Ø 3-4-5-6-8-10mm
1 pcs. per size, bits Art. 8665 Ø 2.5-3.3-4.2-5-6.8-8.5mm
1 magnetic 1/4 hex shank.
In plastic case.
9093
Each 61,10
vuoto
HSS-CO 5%STANDARDTAPS
