TURNING TOOLS
1282
13
Prices in EURO - VAT not included
9782G
9782GE
9783G
HARTMETALL
Product description as Art. 9770G
DIN 4980 ( ISO 6 - UNI 4104)
Right-hand,as shown in the picture. P 30 quality, for steel.
Size
q.
8
10
12
16
20
25
32
Dimensions
mm 8x80 10x90 12x100 16x110 20x125 25x140 32x170
9782G
Each 5,44
5,08
5,82
7,12
8,88 13,50 20,60
vuoto
Product description as Art. 9770G
DIN 4980 ( ISO 6 - UNI 4104)
Right-hand,as shown in the picture. K 10 quality, for cast iron and non-ferrous steel.
Size
q.
8
10
12
16
20
25
32
Dimensions
mm 8x80 10x90 12x100 16x110 20x125 25x140 32x170
9782GE
Each 5,44
5,08
5,82
7,12
8,88 13,50 20,60
vuoto
Product description as Art. 9770G
DIN 4980 (ISO 6 - UNI 4104)
Left-hand, opposite to the one shown in the picture. P 30 quality, for steel.
Size
q.
8
10
12
16
20
25
32
Dimensions
mm 8x80 10x90 12x100 16x110 20x125 25x140 32x170
9783G
Each 5,44
5,08
5,82
7,12
8,88 13,50 20,60
vuoto
TURNINGTOOLS
9784G
9784GE
9785G
HARTMETALL
Product description as Art. 9770G
DIN 4981 (ISO 7 - UNI 4109)
Right-hand,as shown in the picture. P 30 quality, for steel.
Size
h.
10
12
16
20
25
Dimensions
mm 10x6x90 12x8x100 16x10x110 20x12x125 25x16x140
Cutting width
mm 3
3
4
5
6
9784G
Each 7,36
5,28
5,74
6,94
9,90
vuoto
Product description as Art. 9770G
DIN 4981 (ISO 7 - UNI 4109)
Right-hand,as shown in the picture. K 10 quality, for cast iron and non-ferrous steel.
Size
h.
10
12
16
20
25
Dimensions
mm 10x6x90 12x8x100 16x10x110 20x12x125 25x16x140
Cutting width
mm 3
3
4
5
6
9784GE
Each 7,36
5,28
5,74
6,94
9,90
vuoto
Product description as Art. 9770G
DIN 4981 (ISO 7 - UNI 4109)
Left-hand, opposite to the one shown in the picture. P 30 quality, for steel.
Size
h.
10
12
16
20
25
Dimensions
mm 10x6x90 12x8x100 16x10x110 20x12x125 25x16x140
Cutting width
mm 3
3
4
5
6
9785G
Each 7,36
5,28
5,74
6,94
9,90
vuoto
TURNINGTOOLS
9786G
60
HARTMETALL
Product description as Art. 9770G
DIN 282 – For 60° external threading.
External right-hand use. P 30 quality, for steel.
Size
q.
8
10
12
16
20
25
Dimensions
mm 8x80 10x90 12x100 16x115 20x125 25x140
9786G
Each 8,00
8,00
7,64
9,30 12,30 18,60
vuoto
TURNINGTOOLS
9787G
60
HARTMETALL
Product description as Art. 9770G
DIN 283 – For 60° internal threading.
Internal right-hand use. P 30 quality, for steel.
Size
q.
8
10
12
16
20
25
Dimensions
mm 8x120 10x140 12x160 16x180 20x210 25x250
Min. bore Ø
mm 18
20
25
33
40
50
9787G
Each 9,60
8,96 11,20 13,60 17,30 24,10
vuoto
TURNINGTOOLS
9788G
HARTMETALL
Product description as Art. 9770G
DIN 263 - For making internal rebates
Internal right-hand use. P 30 quality, for steel.
Size
q.
8
10
12
16
20
25
Dimensions
mm 8x120 10x140 12x160 16x180 20x210 25x250
Min. bore Ø
mm 20
25
30
40
50
60
Throat width
mm 3,3
3,6
4
5
6
8
9788G
Each 8,96 11,80 12,60 14,10 17,30 24,60
vuoto
