DUPLEX PUNCHING MACHINES
152
2
Prices in EURO - VAT not included
DUPLEX PUNCHING MACHINES
754G 17
new
Orig. Peddinghaus - Art. Mod. 27/250
Fully forged steel composition. Easy to carry, for use even in places that are hard to reach.
Can also be used on workbench (lock in grip).
Great punching force.
Punches and dies in high-resistance steel. (Supplied with 17 mm punch and die). With operating
rod.
For bores and thicknesses up to mm 17x12
For material with R
Kg/mm²
45
Span
mm 50
Punching force
KN 250
Weight
Kg
19
754G 17
Each 978,00
vuoto
DUPLEXPUNCHINGMACHINES
755C
new
755D
new
Orig. Peddinghaus
SPARE PUNCHES AS PER ART. 754 G 17
Punches - Ø connection 18 mm.
Ø
mm
8
9
10 11 12 13 14 15 16 17
755C Each 30,80 30,80 30,80 30,80 30,80 30,80 30,80 30,80 30,80 30,80
vuoto
SPARE MATRIXES AS PER ART. 754 G 17
Ø
mm
8
9
10 11 12 13 14 15 16 17
755D Each 36,10 36,10 36,10 36,10 36,10 36,10 36,10 36,10 36,10 36,10
vuoto
DUPLEXPUNCHINGMACHINES
SPARE PARTS FOR PUNCHING MACHINES
759A
Orig. Peddinghaus
SPARE PUNCHES FOR ART. 720G
Punches – connection Ø 10mm
Ø
mm
3
4
5
6
7
8
9
10
759A
Each 20,60 20,60 20,60 20,60 20,60 20,60 20,60 20,60
Ø
mm
11
12
13
14
15
16
17
18
759A
Each 30,80 30,80 30,80 30,80 30,80 30,80 30,80 30,80
vuoto
SPAREPARTSFORPUNCHINGMACHINES
759B
SPARE DIES FOR ART. 720G
Ø
mm
3
4
5
6
7
8
9
10
Bores
Nr
2
2
2
2
2
2
2
2
759B
Each 56,50 56,50 56,50 56,50 56,50 56,50 56,50 56,50
Ø
mm
11
12
13
14
15
16
17
18
Bores
Nr
1
1
1
1
1
1
1
1
759B
Each 51,40 51,40 51,40 51,40 51,40 51,40 51,40 51,40
vuoto
SPAREPARTSFORPUNCHINGMACHINES
SCREW PUNCHES
759GA
Prod. SCU
Professional model with 3 penetration drills in hardened steel. Punching is achieved by pre-drilling
a tip and by subsequently tightening the central screw.
Suitable for steel sheeting, aluminium, plastics, leather, rubber, etc.
Steel blade thickness 2mm up to Ø 30.5mm, 3mm up to Ø 54mm.
Aluminium blade thickness 2.5mm up to Ø 30.5, 3.5mm up to Ø 54mm.
For bores Ø
mm
12,5 12,7 15,2 16 18,6 20,4 20,5 22,5 25,4 25,5
For bores
PG -
7
9
-
11 13 -
16 -
-
For bores
ISO 12 -
-
16 -
-
20 -
-
25
Pre-bore Ø
mm 9
9
9
9
9 13 13 13 13 13
Screw Ø
mm 8
8
8
8
8 12 12 12 12 12
759GA
Each 16,30 16,30 16,40 17,10 18,10 18,90 18,90 26,10 26,70 26,70
For bores Ø
mm
28,3 30,5 32,5 35 37 38 40,5 47 50,5 54
For bores
PG 21 -
-
-
29 -
-
36 -
42
For bores
ISO -
-
32 -
-
-
40 -
50 -
Pre-bore Ø
mm 13 13 13 13 13 13 13 22 18 22
Screw Ø
mm 12 12 12 12 12 12 12 20 16 20
759GA
Each 28,50 29,10 31,70 33,10 33,30 33,30 36,30 51,20 52,30 54,40
vuoto
SPARE SCREWS FOR ART. 759 GA.
In hardened steel quality 12.9.
Screw Ø
mm
8
12
16
20
Pitch
1
1,5
1,5
1,5
Length
mm 55
65
75
80
For Art. 759GA Ø
mm 12,5 to 18,6 20,4 to 40,5
50,5
47 e 54
O759GA
Each 5,18
9,10
11,30
14,20
vuoto
