OIL-HYDRAULIC PUNCHERS
155
2
Prices in EURO - VAT not included
760GH 8
Orig. Baudat - Art. 50-616 (Mod. L S8)
Straight universal type.
Lever hydraulic control, with reduced strain movement (Particularly suitable for large diameters).
Operating parts in hardened steel,
reinforced sheet arm, insulated handle. Complete with 2 punch holder pins, adapter and spacer.
Punching strength approx. 60 kN (6 t.).
Complete body without punches and dies.
Punches Ø by
mm 15,2 to 100
Punches sheet max. thickness mm 3
Length
mm 335
Weight
Kg
2.6
760GH 8
Each 939,00
Spare pins see Art. 0760 GH 1-0760 GH 2. Spare adapter and spacer see Art. 0760 GH 3 – 0760 GH 4.
vuoto
OIL-HYDRAULICPUNCHERS
760GL
760GM
Orig. Baudat - Art. 62-103/104/105
PUNCHES AND DIES FOR ART. 760 GH – 760 GH 8 – 760 GV
In hardened special steel. Up to Ø 33mm with threaded hole 3/8" x 24UNF. From Ø 35mm with
threaded hole 3/4" x 16UNF.
Supplied in couples.
For bores Ø
mm
15,2 16 16,2 18,6 19
20 20,4 21
22 22,5 24
25
26
27
760GL
Per pair 43,90 55,80 56,10 55,40 68,10 69,90 56,80 68,40 83,60 58,10 83,60 103,00 73,60 76,10
For bores Ø
mm
28,3 30 30,5 32
33
35
37
40
42 43,2 45
47
50
54
760GL
Per pair 64,10 80,10 67,90 138,00 140,00 146,00 83,50 155,00 162,00 162,00 217,00 126,00 202,00 145,00
For bores Ø
mm
55 59,3 60
65
70
80
90
100
760GL
Per pair 213,00 161,00 220,00 277,00 278,00 321,00 773,00 832,00
Attention: from 18.6mm to 100mm, punches and dies are equipped with elastic insert for better guided cutting and longer working life.
Available on request: couples of punches and dies, square and rectangular. PG punches and dies sizes are the following
vuoto
Orig. Baudat - Art. 62-103/104/105
Product description as Art. 760GL
In hardened special steel. Metric measures up to Ø 32,5mm with threaded hole
3/8" x 24UNF. From Ø 40,5mm with threaded hole 3/4" x 16UNF.
Supplied in couples.
For bores Ø
mm
16,5 20,5 25,5 32,5 40,5 50,5 63,5
For screws and pivots
M.
16
20
25
32
40
50
63
760GM
Per pair 43,90 56,80 58,80 70,40 85,90 130,00 163,00
Attention: from 20,5mm to 63,5mm the punches and dies are equipped with elastic insert for better guided cutting and longer working life.
vuoto
OIL-HYDRAULICPUNCHERS
760GN
760GP
760GR
Orig. Baudat - Art. 50-606
STANDARD assortment for plumbers, electricians, sanitary installers, etc.
The set contains:
1 complete puncher Art. 760 GH with punch holder pin.
1 couple for each measure of punches and dies Art. 760 GL from mm. 15,2-18,6-20,4-22,5-28,3-
30,5 complete with elastic insert (except for 15,2mm).
In case.
760GN
Each 1.190,00
vuoto
Orig. Baudat - Art. 50-603
Product description as Art. 760GN
The set contains:
1 complete puncher Art. 760 GH 8 with punch holder pin.
1 couple for each measure of punches and dies Art. 760 GL from mm. 15,2-18,6-20,4-22,5-28,3-
30,5 complete with elastic insert (except for 15,2mm).
In case.
760GP
Each 1.370,00
vuoto
Orig. Baudat - Art. 50-607
Assortment with metric measures, suitable for carpenters, mechanics, workshops, etc.
The set contains:
1 complete puncher Art. 760 GH with punch holder pin.
1 couple for each measure of punches and dies Art. 760 GM from mm. 16,5-20,5-25,5-32,5 - 40,5
complete with elastic insert (except for 16,5mm).
In case.
760GR
Each 1.210,00
When stocks are depleted, we will provide it with handles black instead of yellow.
