190 / 1378
190
PRECISION TORQUE WRENCHES WITHOUT SIZES SCALE
190
3
Prices in EURO - VAT not included
794GC
Orig. Torqueleader - Art. TSN 25D
Product description as Art. 794GA
± 4% tolerance of the scale set torque.
Square drive
inches
1/4
Tightening capacity
Nm 3-25
Tightening capacity
lbf.ft
2-18
Overall length
mm 216
Weight
Kg
0,34
794GC
Each 468,00
vuoto
PRECISION TORQUEWRENCHESWITHOUTSIZESSCALE
794GD
794GE
Orig. Torqueleader
Product description as Art. 794GA
± 4% tolerance of the scale set torque.
Art.
794GD
794GE
Square drive
inches
3/8
3/8
Tightening capacity
Nm 3-25
15-55
Tightening capacity
lbf.ft
2-18
10-40
Overall length
mm 216
324
Weight
Kg
0,34
0,80
Supplier code
TSN 25A
TSN 55
Each 468,00
600,00
vuoto
Art. 794 GE is not EPA marked.
PRECISION TORQUEWRENCHESWITHOUTSIZESSCALE
794GF
Orig. Torqueleader - Art. TSN 125
Product description as Art. 794GA
± 4% tolerance of the scale set torque.
Square drive
inches 1/2
Tightening capacity
Nm 40-125
Tightening capacity
lbf.ft
30-90
Overall length
mm 460
Weight
Kg
1,36
794GF
Each 681,00
Torque wrenches Art. 794 GA to 794 GF can be fixed set at the factory on the desired value (price on request).
PRECISION TORQUEWRENCHESWITHOUTSIZESSCALE
PRECISION TORQUE WRENCHES WITHOUT SIZES SCALE, WITH SIGNAL OUTPUT SISTEM
794GH
new
Orig. Torqueleader
SLIDING TYPE WITHOUT SCALE WITH ELECTRONIC SWITCH (Sw), that allows an external
device to check if the pre-set torque value has been reached and to count how many times this
value has been applied. The wrench is connected to the monitoring device by means of a cable and
can be interfaced with computers, switches etc. This system allows for the automated monitoring of
the application process of tightening in any line production.
Other features of the wrenches similar to Art. 794 GA-B-D-E-F.
The wrenches are supplied with a switch Art. 794 GHA and a cable of the length of approx. 6 m Art.
794 GHB.
Size
5
10
25
55
125
Square drive
inches
1/4
1/4
3/8
3/8
1/2
Tightening capacity
Nm 1-5
2-10
5-25
15-55
40-125
Tightening capacity
lbf.in/ft
10-45
20-90
4-18
10-40
30-90
Overall length
mm 335
335
366
474
610
Weight
Kg
0,53
0,53
0,68
1,14
1,70
Supplier code
TSP 5 Sw TSP 10 Sw TSN 25 A Sw TSN 55 Sw TSN 125 Sw
794GH
Each 951,00
966,00
1.060,00
1.190,00 1.270,00
On request the spanners Art. 794 GH can be supplied pre-calibrated to the desired value for an additional charge.
PRECISION TORQUEWRENCHESWITHOUTSIZESSCALE,WITHSIGNALOUTPUTSISTEM
794GHA
new
Orig. Torqueleader - Art. B25900
ELECTRIC SWITCH FOR Sw type TORQUE WRENCHES, used on all torque wrenches Art. 794
GH 5-10-25-55-125 and 804 GA 2-10-25-65-135. It connects to the line production control system
via cable Art. 794 GHB or 794 GHC.
Capacity of output signal from max. 100 mA DC 30 V to min. 100 uA AC 50 mV.
Supplied without cable.
794GHA
Each 263,00
vuoto
PRECISION TORQUEWRENCHESWITHOUTSIZESSCALE,WITHSIGNALOUTPUTSISTEM
