PRECISION TORQUE WRENCHES WITHOUT SIZES SCALE, WITH SIGNAL OUTPUT SISTEM
191
3
Prices in EURO - VAT not included
794GHB
new
Orig. Torqueleader - Art. D94402
CONNECTION CABLES
between the electrical switch Art. 794 GHA and the line production control system or signal unit
Art. 794 GHE.
Flat cable, total length 5 m.
794GHB
Each 188,00
vuoto
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE,WITHSIGNALOUTPUTSISTEM
794GHC
new
Orig. Torqueleader - Art. D94406
Product description as Art. 794GHB
Coiled cable, total length in in extension approx. 5 m.
794GHC
Each 291,00
vuoto
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE,WITHSIGNALOUTPUTSISTEM
794GHE
new
Orig. Torqueleader - Art. C12870
SERVICE DATA UNIT (SDU) that allows you to amplify, stabilize and adjust the signal transmitted
by the torque wrenches by means of a switch (Sw) Art. 794 and 804 GH 5-10-25-55-125 GA 2-10-
25-65- 135.
This system reduces the risk of failure to report the activation of the torque wrench.
The unit can be powered by 4 AA alkaline batteries (Art. 3600 E, not supplied) or DC 6V. It is
connected to the torque wrenches via cables Art. 794 GHB/C and to the external devices via
output contacts to 5 A for 110 V AC or 24 V DC.
Equipped with 1 YELLOW LED to battery power insufficient, 1 RED LED when no signal is
transmitted, 1 GREEN LED when the signal is transmitted.
794GHE
Each 571,00
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE,WITHSIGNALOUTPUTSISTEM
PRECISION TORQUE WRENCHES
794GM
794GP
Orig. Torqueleader
Sliding model, with scale. High precision tightening on pre-set torque value.
Over-tightening is not possible. Serial assembling and long-term work. Automatic reset. Stainless
steel heads, body in special aluminium alloy, ergonomic non-slip rubber handgrip. Integrated
ratchet function.
Right operation.
Supplied with test certificate as per DIN ISO 6789.
± 6% tolerance of the scale set torque.
Art.
794GM
794GP
Square drive
inches
1/4
1/4
Tightening capacity
Nm
1-5
2-10
Scale division
0,05 Nm
0,1 Nm
Overall length
mm
195
195
Weight
Kg
0,24
0,24
Supplier code
TSC 5
TSC 10
Each
426,00
437,00
PRECISIONTORQUEWRENCHES
794GR
794GS
794GT
Orig. Gedore
Click type.
For precise, even tightening of screws and bolts. Tolerance: ± 3% for each scale reading. High
quality performance ensured. Gedore torque wrenches are characterised by the high resistance
of their light alloy body and alloyed steel component parts. Adjusted using a jointed socket that is
extracted from the handle. Audible signal ("click") on reaching the set torque value. Square drive
for right-handed operation. Two square drives for right/left-handed operation.
Supplied with DIN ISO 6789 test certificate.
Torque wrenches Art. 794GS / 795G 2-6-10-14-22-24A-26-30-34-36E-38-41 are supplied in a
case also designed to hold relevant accessories such as sockets, extensions, ratchet heads, etc.
Art.
794GR
794GS
794GT
Square drive
inches
1/4
1/4
1/4
Tightening capacity
Nm
6-30
6-30
6-30
Tightening capacity
lbf.in
50-270
50-270
50-270
Scale division
1 Nm/10 lbf.in
1 Nm/10 lbf.in
1 Nm/10 lbf.in
Overall length
mm
265
265
265
Weight
Kg
0,6
0,9
0,6
Frame
Simple right D
Simple right D Double right and left D-S
Package in case
Plastic
Plastic box
Plastic
Supplier code
8554-01
8554-02
8559-01
Each
499,00
570,00
520,00
