ANGLE INDICATORS FOR CONTROLLED ANGLE CLAMPING
196
3
Prices in EURO - VAT not included
798GH 3
Orig. Gedore - Art. 8200-01
Professional type.
For angular values clamping. Necessary for nut orientation and final clamping.
Alloy steel goniometer, 360° graduated, with flexible arm, clamping spring and magnet for fixing
point 0°.
Max. tightening capacity Nm 390
Male drive
inches 1/2
Female drive
inches 1/2
798GH 3
Each 313,00
vuoto
ANGLE INDICATORSFORCONTROLLEDANGLECLAMPING
798GH 5
Orig. Gedore - Art. 8200-02
Product description as Art. 798GH 3
Max. tightening capacity Nm 1330
Male drive
inches 3/4
Female drive
inches 3/4
798GH 5
Each 459,00
Torque wrench max. clamping strength includes angular values.
vuoto
ANGLE INDICATORSFORCONTROLLEDANGLECLAMPING
DIRECT READING TORQUE WRENCHES
798GP 1
798GP 1A
798GP 2
Orig. Torqueleader
Model with dial to check tightening. ± 4% tolerance of the scale set torque. Special light alloy
body with rubber ergonomic handle. Double scale with readings in Nm-lbf. in./lbf. ft. For bi-
directional tightening.
Also suitable to determine torque values of already tightened bolts.
Supplied with test certificate in accordance with DIN ISO 6789.
With integrated ratchet. Supplied in synthetic material case
Art.
798GP 1
798GP 1A
798GP 2
Drive
inches
1/4
1/4
1/4
Tightening capacity
Nm 0,8-4
1,6-8,0
2,4-12
Tightening capacity
lbf.in
7-35
14-70
24-120
Scale division
0,1 Nm/1 lbf.in 0,25 Nm/1 lbf.in 0,5 Nm/2 lbf.in
Overall length
mm 244
244
244
Weight
Kg
0,52
0,52
0,52
Supplier code
ADS 4
ADS 8
ADS 12 D
Each 524,00
524,00
524,00
Available on request: same wrenches with audiovideo signal when the pre-set value is reached.
vuoto
DIRECTREADING TORQUEWRENCHES
798GP 3
798GP 4
Product description as Art. 798GP 1
With integrated ratchet. Supplied in synthetic material case
Art.
798GP 3
798GP 4
Drive
inches
3/8
3/8
Tightening capacity
Nm 5-25
8-40
Tightening capacity
lbf.in
48-240
72-360
Scale division
1 Nm/10 lbf.in 1 Nm/10 lbf.in
Overall length
mm 244
244
Weight
Kg
0,52
0,52
Supplier code
ADS 25
ADS 40
Each 524,00
524,00
Available on request: same wrenches with audiovideo signal when the pre-set value is reached.
vuoto
DIRECTREADING TORQUEWRENCHES
798GP 5
798GP 5A
798GP 6
Product description as Art. 798GP 1
With integrated ratchet. Supplied in plastic wallet.
Art.
798GP 5
798GP 5A
798GP 6
Drive
inches
1/2
1/2
1/2
Tightening capacity
Nm 16-80
32-160
40-200
Tightening capacity
lbf.ft
12-60
24-120
30-160
Scale division
2 Nm/1 lbf.ft
2,5 Nm/2 lbf.ft
5 Nm/5 lbf.ft
Overall length
mm 435
515
515
Weight
Kg
1,36
1,41
1,41
Supplier code
BDS 80 E
BDS 160
BDS 200
Each 796,00
796,00
796,00
vuoto
Available on request: same wrenches with audiovideo signal when the pre-set value is reached.
DIRECTREADING TORQUEWRENCHES
