TORQUE WRENCHES WITH FEMALE DRIVE
203
3
Prices in EURO - VAT not included
TORQUE WRENCHES WITH FEMALE DRIVE
804GH
804GL
804GM
9x12
Orig. Torqueleader
Dividing model providing real accuracy for repeating processes with a set value.
Robust construction which provides long performance life when installing bulk items. Tolerance: ±
6% for each scale reading.
Automatic disconnection with 20° angular rod body movement. Automatic reset feature.
Micrometer Nm scale providing a clear view of the values.
Ergonomic adjustment by rotating the soft rubber handle complete with safety lock, positioned at
the far end. Can be used with both left and right handed operation.
Equipped with items certified as per DIN ISO 6789.
Type with frontal connection of inserts.
Art.
804GH
804GL
804GM
Inserts drive
mm
9x12
9x12
9x12
Tightening capacity
Nm
1-5
2-10
5-25
Scale division
0,025 Nm
0,05 Nm
0,1 Nm
Overall length
mm
230
230
303
Weight
Kg
0,29
0,3
0,7
Supplier code
ATB 5 G
ATB 10 G
ATB 25 G
Each
310,00
310,00
309,00
vuoto
Art. 804 GM is not marked EPA. Art. 804GM running out of stock.
TORQUEWRENCHESWITHFEMALEDRIVE
804GP
9x12
Orig. Carolus
Release type model.
Suitable for precision installations. Easy to handle: Tolerance: ± 3% for each scale reading. Dual
micrometer scale Nm/lbf.ft with handle and values which can be viewed by using a magnifying
glass for easy reading. Can be adjusted by rotating the ergonomic plastic handle with a safety
lock for final positioning.
For use with left and right handed operation.
Equipped with items certified as per DIN ISO 6789.
Type with frontal connection of inserts.
Size
25
50
100
150
Inserts drive
mm 9x12
9x12
9x12
9x12
Tightening capacity
Nm 5-25
10-50
20-100
30-150
Tightening capacity
lbf.ft
4-18
8-37
15-75
20-110
Scale division
0,1 Nm
0,25 Nm
0,5 Nm
1 Nm
Overall length
mm
274
324
369,5
460,5
Supplier code
4912.025
6912.050
5912.100
5912.150
804GP
Each
195,00
195,00
195,00
203,00
vuoto
TORQUEWRENCHESWITHFEMALEDRIVE
804GR
14x18
Product description as Art. 804GP
Type with frontal connection of inserts.
Size
200
300
400
Inserts drive
mm 14x18
14x18
14x18
Tightening capacity
Nm 40-200
60-300
80-400
Tightening capacity
lbf.ft
30-150
45-220
60-300
Scale division
1 Nm
1 Nm
1 Nm
Overall length
mm 470,5
561,5
648,5
Supplier code
5918.200
5918.300
8918.400
804GR
Each
203,00
284,00
405,00
vuoto
TORQUEWRENCHESWITHFEMALEDRIVE
804GS
804GT
805GA
805GB
9x12
Orig. Gedore
Click type. Handy construction. ± 3% tolerance of the scale set torque.
Double scale with graduation Nm/lbf.ft on handle below a window with a magnifying-glass effect
that makes reading easier.
Adjustment obtained by rotating the ergonomically shaped nylon handgrip, safety lock at the
extremity. For controlled bi-directional tightening.
Supplied with test certificate as per DIN ISO 6789.
With end fitting frontal connection.
Art.
804GS
804GT
805GA
805GB
Inserts drive
mm 9x12
9x12
9x12
9x12
Tightening capacity
Nm 2-25
5-50
10-100
20-150
Tightening capacity
lbf.ft
1,5-18
4-37
8-75
15-110
Scale division
0,1 Nm
0,25 Nm
0,5 Nm
1 Nm
Overall length
mm
274
324
370
461
Weight
Kg
0,3
0,45
0,6
0,8
Supplier code
4101-02
4101-05
4100-01
4200-02
Each
212,00
222,00
235,00
264,00
vuoto
