TORQUE WRENCHES
200
3
Prices in EURO - VAT not included
803B
Product description as Art. 803A
With square through drive and socket stop pin.
Size
400
550
750
850
Square drive
inches
3/4
3/4
3/4
3/4
Tightening capacity
Nm 80-400
110-550
150-750
250-850
Tightening capacity
lbf.ft
60-300
80-405
110-550
185-630
Scale division
1 Nm
1 Nm
1 Nm
1 Nm
Overall length
mm 715,5
953,5
1228,5
1375,5
Weight
Kg
2,4
3,8
4,9
5,2
Supplier code
DMK 400 DMK 550 DMK 750 DMK 850
803B
Each 653,00
1.010,00 1.160,00
1.280,00
Wrenches Art. 803 A 100 - 200 - 300 and 803 B 400 with sockets and extensions can be supplied on request in a metal case.
vuoto
Spare 1/2 square drives with disk, for torque wrenches Art. 803 A 100 - 200 - 300.
O803C
Each 25,10
vuoto
Spare square connectors for wrenches Art. 803 B 400 - 550 - 750 - 850 see Art. 974 RD.
TORQUEWRENCHES
803E
Orig. Gedore - Dremaster UK
Release type model.
Suitable for precision installations. Sturdy construction, easy to handle with ratchet movement
towards the right (is only able to move to the left by unscrewing). Can be adjusted by rotating the
ergonomic handle with safety lock, which includes visual monitoring located at the far end. An
additional quick adjustment is also possible by using round tenders, although these are not
provided. Dual component handle with soft, non-slip grip with a clear path through to the centre
providing an accurate hold and an accurate calibration process. Tolerance: ± 3% for each scale
reading. Dual scale Nm/lbf.ft reading which can be selected by using the cursor, and which helps
to avoid any potential reading errors. Micrometric adjustments with Nm values.
Equipped with items certified as per DIN ISO 6789:2003.
Type II, Class A.
Size
100
200
300
Square drive
inches
1/2
1/2
1/2
Tightening capacity
Nm 20-100
40-200
60-300
Tightening capacity
lbf.ft
15-75
30-150
45-220
Scale division
0,5 Nm 1 Nm
1 Nm
Overall length
mm 438
529
620
Weight
Kg
1,2
1,4
1,6
Supplier code
DMUK 100 DMUK 200 DMUK 300
803E
Each 455,00
475,00
519,00
vuoto
TORQUEWRENCHES
TORQUE WRENCHES WITHOUT SCALE
803G
9x12 14x18
Orig. Gedore
Model without scale. High precision tightening on pre-set torque value. ± 3% tolerance of the
scale set torque. Audible acustic signal ("click") on reaching of the set torque value, angled
movement at 3° of the rod, to allow tightening even in difficult-to access places. Handy and light
construction. Automatic reset. "FS" torque wrenches must be preset directly on the place of use
by means of suitable torque testers Art. 793 GC-D/793 GL/793 GT and fixed on the desired value
within the tightening range of the wrenches mentioned below. Bi-directional tightening. Possibility
to unscrew without changing the wrench (function available only on this model).
Supplied with test certificate as per DIN ISO 6789.
Torque wrenches Art. 803 G and 803 GP can be fixed set at the factory
on the desired value (price on request).
Size
25
50
85
200
Inserts drive
mm 9x12
9x12
9x12
14x18
Tightening capacity
Nm 2-25
5-50
15-85
20-200
Overall length
mm 180
240
320
400
Weight
Kg
0,21
0,27
0,34
0,75
Supplier code
4150-25
4150-50
4150-85
4151-20
803G
Each 187,00
192,00
205,00
272,00
For use with torque testers Art. 793 GC-D, heads Art. 806 GD 1/4 - 3/8 are required. For use with
torque testers Art. 793 GL, heads Art. 806 GD 3/8 - 1/2 or Art. 806 GE 3/8 - 1/2 are required (for
Art. 803 G 200 heads Art. 806 GM 1/2 or Art. 806 GP 1/2 ar
