TORQUE WRENCHES
199
3
Prices in EURO - VAT not included
802GA
802GB
802GC
Orig. Gedore
Product description as Art. 801GR
Art.
802GA
802GB
802GC
Square drive
inches
1/2
1/2
1/2
Tightening capacity
Nm 10-100
20-200
60-300
Tightening capacity
lbf.ft
8-75
15-150
45-220
Scale division
0,5 Nm
1 Nm
1 Nm
Overall length
mm 395
485
577
Weight
Kg
0,9
1,1
1,4
Supplier code
4550-10
4550-20
4550-30
Each 284,00
306,00
351,00
vuoto
TORQUEWRENCHES
802GE
new
802GF
802GH
Product description as Art. 801GR
Art.
802GE
802GF
802GH
Square drive
inches
3/4
3/4
3/4
Tightening capacity
Nm 75-400
100-550
140-750
Tightening capacity
lbf.ft
55-300
75-405
105-550
Scale division
1 Nm
1 Nm
1 Nm
Overall length
mm 686
957
1236
Weight
Kg
2
3,8
4,8
Supplier code
4550-40
4550-55
4550-75
Each 579,00
914,00
1.040,00
vuoto
Square drive with spare disk.
Size
01
02
2
5
For Art.
801 GR/S 801 GT(mod.4549) 801 GS/T(mod.4550) 802 GA/B/C/E
Square drive
inches 1/4
3/8
3/8
1/2
Overall length
mm 33
37
46
50
Supplier code
4550-75
4550-75
4550-75
4550-75
O802GH
Each 12,20
11,10
12,40
10,30
vuoto
TORQUEWRENCHES
802GZ 1
802GZ 2
802GZ 3
Click type, suitable to precise tightening. Handy construction with toothed ratchet mechanism for
right operation (left operation only to unscrew). Adjustment obtained by rotating the ergonomically
shaped handgrip, safety lock at the extremity. ± 3% tolerance of the scale set torque. Double scale
with graduation Nm/lbf.ft on handle below a window with a magnifying-glass effect for a more
precise reading.
Supplied with test certificate as per DIN ISO 6789.
Art.
802GZ 1
802GZ 2
802GZ 3
Square drive
inches
1/2
1/2
1/2
Tightening capacity
Nm 20-100
40-200
60-300
Tightening capacity
lbf.ft
20-75
30-150
50-220
Scale division
0,5 Nm
1 Nm
1 Nm
Overall length
mm 410
500
590
Weight
Kg
1
1,2
1,4
Supplier code
5550-10
5550-20
5550-30
Each 390,00
407,00
444,00
vuoto
TORQUEWRENCHES
803A
Orig. Gedore - Dremaster K
Release type model.
Suitable for precision installations. Handy left and right side ratchets, which can be reversed
through the framework. Can be adjusted by rotating the ergonomic handle with safety lock, which
includes visual monitoring located at the far end. An additional quick adjustment is also possible
by using round tenders, although these are not provided. Dual component handle with soft, non-
slip grip with a clear path through to the centre providing an accurate hold and an accurate
calibration process. Tolerance: ± 3% for each scale reading. Dual scale Nm/lbf.ft reading which
can be selected by using the cursor, and which helps to avoid any potential reading errors.
Micrometric adjustments with Nm values.
Equipped with items certified as per DIN ISO 6789:2003.
Type II, Class A.
With reversible square drive, anti-slip disk and quick, safe button release of sockets.
Size
100
200
300
Square drive
inches
1/2
1/2
1/2
Tightening capacity
Nm 20-100
40-200
60-300
Tightening capacity
lbf.ft
15-75
30-150
45-220
Scale division
0,5 Nm
1 Nm
1 Nm
Overall length
mm 423,5
514,5
606,5
Weight
Kg
1,1
1,3
1,5
Supplier code
DMK 100
DMK 200
DMK 300
803A
Each 313,00
333,00
396,00
vuoto
