SELF-TIGHTENING CHUCKS
445
6
Prices in EURO - VAT not included
1525G
Prod. SCU
INDUSTRIAL PERFORMANCE PRECISION.
For industrial related use on drill presses, boring machines, numerically programmed machine
tools, etc. Steel bodywork. Sliding parts are fully hardened and ground.
Rotation precision 0.04mm.
Type
6
8
10
13
16 16A
For tips Ø
mm 0,3-6,5 0,3-8 0,3-10 0,3-13 3-16 3-16
Drive
B10 B12 B12 B16 B16 B18
Drive type
DIN DIN DIN DIN DIN DIN
1525G
Each 130,00 124,00 134,00 153,00 176,00 176,00
On request, the same chucks can be supplied with TITANIUM clamps.
vuoto
SELF-TIGHTENINGCHUCKS
90° ANGULAR ADAPTORS FOR DRILLS
1544
Prod. SCU
To be fixed to portable drill chuck for 90° angle drilling.
For RIGHT/LEFT rotation. Hexagonal shank ø 9mm. In cast aluminium. 3/8x24 male shank,
without chuck.
Chuck shank max length approx. 43mm
Drill shank max length approx. 139mm
Max rotation speed 2100 rpm.
1544
Each 76,10
For included chucks see Art. 1495 G 10P and 1500G 10E. While using the angular adaptor, the
drill must be in the rotation mode (not in the percussion mode).
vuoto
90°ANGULARADAPTORSFORDRILLS
ANGULAR THREE-JAWS CHUCKS
1545
Prod. SCU
To be fixed to portable drill chuck for 90° angle drilling.
For RIGHT/LEFT rotation. Hexagonal shank ø 9mm. In cast aluminium. With three-jaws chuck
1.5-10mm, 3/8x24 male shank and wrench.
Chuck side max length approx. 143mm
Shank side max length approx. 143mm
Max rotation speed 2100 rpm.
1545
Each 89,90
For spare chucks up to 10mm, see Art. 1495 G 10P and 1500G 10E. When using angular chucks,
the drill must be in the rotation mode (not in the percussion mode).
vuoto
ANGULARTHREE-JAWSCHUCKS
1545A
To be fixed to portable drill chuck for 90° angle drilling.
For RIGHT/LEFT rotation. Hexagonal shank ø 9mm. In cast aluminium. Complete with chuck
without wrench and rapid closing system 1.5-10mm, 3/8x24 male shank.
Chuck side max length approx. 110mm
Shank side max length approx. 147mm
Max rotation speed 2100 rpm.
1545A
Each 105,00
For spare chucks up to 10mm, see Art. 1512 GE 10 and 1513G 10. When using angular chucks,
the drill must be in the rotation mode (not in the percussion mode).
ANGULARTHREE-JAWSCHUCKS
CHUCK ADAPTORS
1546GA
1546GB
1546GE
1546GF
Prod. SCU
For fitting chuck shanks into drills, screwdrivers, etc.
Suitable for transforming chucks with 1/2x20 female thread shank into 3/8x24 female thread.
1546GA
Each 2,36
vuoto
Product description as Art. 1546GA
Suitable for transforming chucks with 3/8x24 female thread shank into 3/8x24 male thread.
1546GB
Each 2,12
vuoto
Product description as Art. 1546GA
Suitable for transforming chucks with 1/2x20 female thread shank into 3/8x24 male thread.
1546GE
Each 3,90
vuoto
Product description as Art. 1546GA
Suitable for transforming chucks with 3/8x24 female thread shank into 1/4 E6,3 hexagonal shank.
1546GF
Each 3,46
For adaptors with SDS-plus shank see Art. 1340GR_22.
