450 / 1378
450
DIN 2080 MILLING CUTTER HOLDER CHUCKS WELDON MODEL
450
6
Prices in EURO - VAT not included
DIN 2080 MILLING CUTTER HOLDER CHUCKS WELDON MODEL
1560GAB
Prod. SCU
For milling cutters with Weldon shanks. High-precision. Max centring of milling cutters with the
highest turning moments.
DIN 2080 shank, internally threaded end.
d mills drive Ø
mm
6
8
10
12
16
20
Shape/ thread K/G
ISO 40
M16
ISO 40
M16
ISO 40
M16
ISO 40
M16
ISO 40
M16
ISO 40
M16
Height L
mm 50
50
50
50
50
50
Height d1
mm 25
28
35
42
48
50
1560GAB
Each 122,00 110,00 134,00 134,00 134,00 134,00
vuoto
DIN 2080MILLINGCUTTERHOLDERCHUCKSWELDONMODEL
DIN 2080 MILLING CUTTER HOLDER CHUCKS WITH FIXED DRAGGING
1560GAC
Prod. SCU
For milling cutters with hole connection. High-precision, max centring of milling cutters with the
highest turning moments.
DIN 2080 shank, internally threaded end.
d mills bore Ø
mm
16
22
27
32
Shape/ thread K/G
ISO 40 M16 ISO 40 M16 ISO 40 M16 ISO 40 M16
Height L
mm 17
19
21
24
Height L1
mm 36
36
36
45
Height d1
mm 32
40
48
63
1560GAC
Each 107,00
107,00
107,00
107,00
For cross-shaped clamping wrenches see Art. 911 GP.
vuoto
DIN 2080MILLINGCUTTERHOLDERCHUCKSWITH FIXEDDRAGGING
DIN 2080 MORSE CONE REDUCTION CHUCKS FOR MILLING CUTTERS
1560GAE
Prod. SCU
For milling cutters with Morse taper shank, internally threaded. High-precision, max centring of
milling cutters with the highest turning moments.
DIN 2080 shank, internally threaded end.
Mills drive K1
C.M.
1
2
3
4
Shape/ thread K/G
ISO 40
M16
ISO 40
M16
ISO 40
M16
ISO 40
M16
Height L
mm 50
50
65
95
Height d
mm 25
32
40
48
1560GAE
Each 150,00 150,00 150,00 160,00
vuoto
DIN 2080MORSECONEREDUCTIONCHUCKSFORMILLINGCUTTERS
DIN 2080 MORSE CONE REDUCTION CHUCKS FOR DRILLS
1560GAF
Prod. SCU
For drill bits with Morse taper shank. High-precision, max centring of drill bits with the highest
turning moments.
DIN 2080 shank, internally threaded end.
Tips drive K1
C.M.
1
2
3
4
Shape/ thread K/G
ISO 40
M16
ISO 40
M16
ISO 40
M16
ISO 40
M16
Height L
mm 50
50
65
95
Height d
mm 25
32
40
48
1560GAF
Each 148,00 148,00 148,00 153,00
vuoto
DIN 2080MORSECONEREDUCTIONCHUCKSFORDRILLS
DIN 2080 MONOLITHIC DRILL CHUCKS
1560GAL
Prod. SCU
For drill bits with cylindrical shank. High-precision, max centring of drill bits with the highest
turning moments.
DIN 2080 shank, internally threaded end.
For tips Ø up to
mm
13
16
Shape/ thread K/G
ISO 40
M16
ISO 40
M16
Height L
mm 87
100
Height D
mm 51
58
1560GAL
Each 410,00 430,00
vuoto
DIN 2080MONOLITHICDRILLCHUCKS
