512 / 1378
512
AIR SCREW DRIVERS
512
7
Prices in EURO - VAT not included
1729G 2E
1/4 ,,
Prod. Pneutec - Art. UT 8960
Straight type with step adjustment of the tightening force by means of the external locking ring
installed on the device front side.
Reversible operation. Quick coupling for 1/4" hex inserts drive. Light alloy construction, coating in
synthetic material and steel working parts. Lightweighted and reduced dimensions to be very
handy. Blast pipe at the grip lower extremity.
Torque
Nm 0,6 to 6
Air consumption
l/sec
1
No-load speed
rev/min 1700
Noise level
dB 77
Vibrations
m/s²
< 2,5
Air drive
inches 1/4
Weight
Kg
0,8
1729G 2E
Each 349,00
For inserts see Art. 1994 GH to Z. Operating pressure: Atm 6,3.
vuoto
AIRSCREW DRIVERS
1729G 2L
1/4 ,,
Prod. Pneutec - Art. UT 5935
Pistol-grip type.
Reversible operation. 1/4" hex inserts drive. Light alloy construction with steel working parts.
Lightweighted and reduced dimensions to be very handy. Blast pipe at the grip lower extremity.
Max torque
Nm 6
Air consumption
l/sec
2
No-load speed
rev/min 1800
Noise level
dB 86,8
Vibrations
m/s²
< 2,5
Air drive
inches 1/4
Weight
Kg
1,2
1729G 2L
Each 225,00
For inserts see Art. 1994 GH to Z. Operating pressure: Atm 6,3.
vuoto
AIRSCREW DRIVERS
1729G 3
1/4 ,,
Prod. Pneutec - Art. UT 5964
Pistol grip with torque control.
Adjustable clutch. Reversible operation. 1/4" hex inserts drive. Light alloy construction with steel
working parts. Lightweighted and reduced dimensions to be very handy. Blast pipe at the grip
lower extremity.
Max torque
Nm 6
Air consumption
l/sec
2
No-load speed
rev/min 1800
Noise level
dB 87,1
Vibrations
m/s²
3,7
Air drive
inches 1/4
Weight
Kg
1,6
1729G 3
Each 243,00
For inserts see Art. 1994 GH to Z. Operating pressure: Atm 6,3.
vuoto
AIRSCREW DRIVERS
1729G 3F
1/4 ,,
Prod. Pneutec - Art. UT 8963
Pistol-grip type with step adjustment of the tightening force by means of the external locking ring
installed on the device front side.
Reversible operation. Quick coupling for 1/4" hex inserts drive. Light alloy construction, coating in
synthetic material and steel working parts. Lightweighted and reduced dimensions to be very
handy. Blast pipe at the grip lower extremity.
Torque
Nm 1 to 9
Air consumption
l/sec
1
No-load speed
rev/min 750
Noise level
dB 76
Vibrations
m/s²
< 2,5
Air drive
inches 1/4
Weight
Kg
0,9
1729G 3F
Each 443,00
For inserts see Art. 1994 GH to Z. Operating pressure: Atm 6,3.
vuoto
AIRSCREW DRIVERS
OILS FOR AIR TOOLS
1730G
Orig. Ewo - Art. 583
Special synthetic oil for compressed air lubricators of pneumatic tools. While protecting tools it
increases their lifetime and performances even in difficult conditions such as high/low
temperatures, dirt, etc. It is biological. It does not contain poisonous substances, easy to be
disposed of. Supplied in handy 1l bottles, transfer pipe included.
1730G
Each 15,80
Viscosity category VG 32 - ISO 3448 (Viscosity 40°C - 32 mm²/s).
vuoto
OILSFORAIR TOOLS
