508 / 1378
508
AIR ROTARY DIE GRINDERS
508
7
Prices in EURO - VAT not included
AIR ROTARY DIE GRINDERS
1719GP
new
Prod. Pneutec - Art. UT 5715
Corner model.
Low air consumption.
High manoeuvrability and comfort, body made from extremely sturdy composite material. Air
outlet on the side/back which can be rotated 360°.
Collet chuck.
For tools with shaft Ø mm 6
Air consumption
l/sec 2,3
No-load speed
rev/min 20000
Length
mm 165
Noise level
dB 79
Vibrations
m/s²
< 2,5
Air drive
inches 1/4
Weight
Kg
0,5
1719GP
Each 187,00
Operating pressure Atm 6,3.
For spare pliers see Art. O1719 GS.
vuoto
AIRROTARYDIEGRINDERS
1719GS
Prod. Pneutec - Art. UT 8723
Angular type.
Big and spaced unloading device, SILENCED, for lowering the acoustic pressure to
dB 77. Aluminium body, synthetic material coated. Collet chuck.
For tools with shaft Ø mm 6
Air consumption
l/sec
8
No-load speed
rev/min 22000
Length
mm 165
Noise level
dB 77
Vibrations
m/s²
< 2,5
Air drive
inches 1/4
Weight
Kg
0,6
1719GS
Each 198,00
Operating pressure: Atm 6,3.
vuoto
Spare collets Ø 6mm. For Art. 1719 GP and 1719 GS.
O1719GS
Each 28,90
vuoto
AIRROTARYDIEGRINDERS
1719GT
Prod. Pneutec - Art. UT 8713
Angular type.
Restricted size, industrial type, ideal when working in confined spaces. Extremely high frequency
rotation with low rev loss, even when the tool is under considerable pressure. Particularly easy to
handle. Collet chuck.
Head width 20mm, head height 44mm, Ø body 19mm.
For tools with shaft Ø mm 3
Air consumption
l/sec 0,4
No-load speed
rev/min 70000
Length
mm 150
Noise level
dB 77
Vibrations
m/s²
< 2,5
Weight
Kg
0,2
1719GT
Each 243,00
Operating pressure Atm 6,3.
vuoto
AIRROTARYDIEGRINDERS
1720GA
Prod. Pneutec - Art. UT 8750 M
Angular type.
With horizontal disk and protection. For cutting and grinding metals. Light alloy body with double
handle for perfect balancing. Silenced side air discharge. Switch with safety lever.
M14 threaded pin with flange for holes Ø 22mm.
For wheels Ø/bore
mm 115-125/22
Air consumption
l/sec
10,8
No-load speed
rev/min 12000
Noise level
dB
82,9
Vibrations
m/s²
5,1
Air drive
inches
1/4
Weight
Kg
2
1720GA
Each 469,00
For spare grinding wheels and sanding disks hole 22mm, see SONNENFLEX program. For steel
brushes, M14 hole see from art. 1819 S to 1822 L. Operating pressure: Atm 6,3.
vuoto
AIRROTARYDIEGRINDERS
