507 / 1378
507
AIR ROTARY DIE GRINDERS
507
7
Prices in EURO - VAT not included
1719G 2
Prod. Pneutec - Art. UT 8721
Stylus type.
Big and spaced unloading device, SILENCED, for lowering acoustic pressure to dB 77. Aluminium
body, synthetic material coated.
High-frequency rotation with limited rpm reduction, even under strong pressure. Collet chuck. 6
bar power: KW 0.4.
For tools with shaft Ø mm 6
Air consumption
l/sec
8
No-load speed
rev/min 22000
Length
mm 175
Noise level
dB 77
Vibrations
m/s²
< 2,5
Air drive
inches 1/4
Weight
Kg
0,6
1719G 2
Each 217,00
For tools with shank Ø mm 3 - see Art. 8148 A - G. Operating pressure: Atm 6,3
vuoto
Spare collets Ø 6mm, for Art. 1719 G/2.
O1719G 2
Each 28,90
vuoto
AIRROTARYDIEGRINDERS
1719GC
Prod. Pneutec - Art. UT8710 D
Stylus type, professional use.
High-frequency rotation with limited rpm reduction, even under strong pressure.
Particularly handy for use of light alloys. Collet chuck.
6 bar power: KW 0.2.
For tools with shaft Ø mm 6
Air consumption
l/sec 4,6
No-load speed
rev/min 25000
Length
mm 165
Noise level
dB 79
Vibrations
m/s²
< 2,5
Air drive
inches 1/4
Weight
Kg
0,5
1719GC
Each 187,00
Operating pressure: Atm 6,3.
vuoto
Spare collets Ø 6mm, for Art. 1719 GC.
O1719GC 1
Each 36,80
vuoto
Additional collets Ø 3mm, for Art. 1719 GC.
O1719GC 2
Each 33,10
vuoto
AIRROTARYDIEGRINDERS
1719GF
Prod. Pneutec - Art. UT 8712 A
Stylus type.
Small, for industrial use. Big and spaced unloading device.
Very high-frequency rotation with limited rpm reduction, even under strong pressure. Particularly
handy. Collet chuck.
For tools with shaft Ø mm 3
Air consumption
l/sec 0,6
No-load speed
rev/min 54000
Length
mm 150
Noise level
dB 72
Vibrations
m/s²
< 2,5
Weight
Kg
0,2
1719GF
Each 319,00
Operating pressure: Atm 6,3
vuoto
Spare collets Ø 3mm, for Art. 1719 GF.
O1719GF
Each 18,60
vuoto
AIRROTARYDIEGRINDERS
