PULLEY BLOCKS
615
8
Prices in EURO - VAT not included
2133F
For steel ropes. Ball bearing type. Openable on one side.
Sturdy finish with hook in forged steel and safety lock.
Pulleys in solid steel. High-tensile.
Opening/closing ratchet operated by hook swiveling.
wheel Ø
mm
105
130
150
180
200
Thoat width
mm 15
17
19
21
23
Load capacity
Kg 1000 1500 2000 3000 4000
Weight
Kg
4,3
5
7,5
10,5
16,5
2133F
Each 144,00 167,00 206,00 273,00 385,00
vuoto
PULLEYBLOCKS
MANUAL CHAIN HOISTS
2133H
Prod. SCU
Lever type. Manufactured in compliance with EUROPEAN standards.
In hardened cast steel. Gears in hardened solid steel. Upper and lower swivel hooks in hardened
steel, with safety latch. Load chain in special, DIN 5684, zinc-plated steel. Double braking system
on the friction. Tested to 50% over the maximum load limit. Supplied with 1.5m long load chain.
Lever with rubber handgrip.
Load capacity
Kg
750
1500 3000
Chain paths
No
1
1
1
Max strain on lever
Kg
14
22
32
Minimum distance between hooks mm 325
380
480
Weight with chain
Kg
7
11
21
2133H
Each 302,00 362,00 482,00
vuoto
MANUALCHAINHOISTS
2133L
Chain type. Manufactured in compliance with EUROPEAN standards.
In hardened cast steel. Gears in hardened solid steel. Gearing over roller bearings. Reduction
unit in grease-bath sump. Upper and lower swivel hooks in hardened steel, with safety latch. Load
and operating chains in special, DIN 5684, zinc-coated steel. Double automatic braking system.
Load chain stop device. Tested to 50% over the maximum load limit.
Supplied with 3m long load chain and 3m long operating chain.
Load capacity
Kg
500
1000 2000 3000 5000
Chain paths
No
1
1
1
2
2
Strain on operating chain
Kg
22
30
45
34
38
Minimum distance between hooks mm 255
306
386
486
616
Weight with chains
Kg
8
10
18
24
36
2133L
Each 201,00 225,00 306,00 430,00 574,00
Loads up to 10000-20000 kg are supplied on request.
vuoto
MANUALCHAINHOISTS
BEAM CLAMPS
2133M
Prod. SCU
Manufactured in compliance with EUROPEAN standards.
Suitable for fixing lever hoists (Art. 2133 H) and chain hoists (Art. 2133 L) on double-T beams.
In special steel, with threaded screw and bolster for fast and safe adjustment.
Load capacity
Kg
1000
2000
3000
Min/max beam width
mm 75 to 220 75 to 220 80 to 320
Pliers min/max width
mm 180 to 360 180 to 360 235 to 490
Beam thickness
mm 26
26
35
Pliers lateral thickness
mm 64
74
103
Hoist drive Ø
mm 22
22
24
Weight
Kg
4,5
5
10,5
2133M
Each 72,30
81,40
145,00
vuoto
BEAMCLAMPS
TROLLEYS FOR MANUAL COAIN HOISTES
2133P
Prod. SCU
Manufactured in compliance with EUROPEAN standards.
Pushing movement, apt for manual chain hoists (art. 2133 L), sliding on lower flange f double T-
beams, conical and flat. With fall-protection and anti-tilting devices. Possibility to change the
distance between wheels. In special steel, with wheels on ball bearings.
Load capacity
Kg
500
1000
2000
3000
Beam lower wing width by mm 50 to 100 58 to 131 80 to 143 90 to 150
Weight
Kg
5,3
9
16
25
2133P
Each 109,00 157,00 199,00 296,00
