619 / 1378
619
THIMBLES, ROPE CLIPS AND SCREW PIN SHACKLES
619
8
Prices in EURO - VAT not included
THIMBLES, ROPE CLIPS AND SCREW PIN SHACKLES
2155
Prod. SCU
Galvanised steel type.
Zinc-coated thimbles.
For ropes Ø
mm
3
4
5
6
8
10
12
2155
Each 0,12
0,14
0,16
0,20
0,28
0,34
0,46
For ropes Ø
mm
14
16
20
22
25
2155
Each 0,54
0,72
1,64
1,78
2,46
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2156
Fully forged and galvanised steel type. In compliance with the Machinery Directive 89/392EEC.
Zinc-coated rope clips.
For ropes Ø
mm
3
5
6
8
10
11
12
2156
Each 0,34
0,42
0,54
0,60
0,86
0,92
1,36
For ropes Ø
mm
14
16
20
22
24
2156
Each 1,56
1,88
2,86
3,10
3,68
Size mm 3 not marked "CE" for small dimension.
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2157
Product description as Art. 2156
Zinc-coated screw pin shackles, with marked displacement.
Pivot Ø
mm
5
6
8
10
11
12
14
Working load
Ton 0,10
0,16
0,25
0,40
0,50
0,63
0,8
2157
Each 0,46
0,66
1,10
1,30
1,56
1,88
2,54
Pivot Ø
mm
16
20
22
25
Working load
Ton
1
1,6
2
2,5
2157
Each 3,76
6,52
8,82 12,10
Sizes mm 5 and 6 not marked "CE" for small dimension.
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2158A
INOX
Stainless steel type AISI 316.
Stainless steel thimbles.
For ropes Ø
mm
3
4
5
6
8
10
12
2158A
Each 0,42
0,48
0,52
0,78
1,32
2,30
2,96
For ropes Ø
mm
14
16
20
2158A
Each 5,28
7,70 11,80
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2158B
INOX
Product description as Art. 2158A
Stainless steel rope clips.
For ropes Ø
mm
3
5
6
8
10
12
14
2158B
Each 1,12
1,40
1,56
2,36
3,66
5,90
6,66
For ropes Ø
mm
16
20
22
26
2158B
Each 9,06 12,90 17,40 20,70
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2158E
INOX
AISI 316 stainless steel type. Not to be used for lifting.
Stainless steel screw pin shackles.
Pivot Ø
mm
4
5
6
8
10
12
14
Working load
Ton 0,03
0,06
0,10
0,20
0,30
0,50
0,60
2158E
Each 1,48
1,56
2,06
3,64
6,24 10,80 16,10
Pivot Ø
mm
16
20
Working load
Ton 0,80
1
2158E
Each 23,20 38,20
vuoto
THIMBLES,ROPECLIPSANDSCREWPINSHACKLES
2158F
INOX
AISI 316 stainless steel model.
Conforms with 89/392 CEE Machinery Directive.
Stainless steel clips.
Pivot Ø
mm
8
10
12
14
16
20
Working load
Ton 0,25
0,40
0,63
0,80
1
1,60
2158F
Each 4,02
6,80 11,90 17,70 25,60 42,10
For the dimensions of redances - shackles - clips see technical tables at the end of the catalogue.
