617 / 1378
617
EYE HOIST HOOKS
617
8
Prices in EURO - VAT not included
EYE HOIST HOOKS
2133V
Prod. SCU
Fixed type, made from special hardened carbon steel. Safety latch.
Painted finish. Marked with load limit in tons.
Load capacity
Kg
800
1000 1600 2000 3200 5000 7500
Weight
Kg 0,28
0,39
0,62
0,91
1,90
3,70
6,80
Height
mm 110
125
145
162
200
255
316
Eye Ø
mm 19
22
28
32
38
51
63
Max hook opening
mm 23
26
28
31
32
40
51
2133V
Each 3,84
5,18
8,20 12,10 19,20 37,10 66,90
The above-mentioned dimensions may vary at the manufacturer’s discretion.
vuoto
EYEHOISTHOOKS
2133VE
Fixed model, made from GRADE 80 stainless steel, hardened. Safety lock.
Enamel finish. Provides an indication of flow rate in tonnes.
Load capacity
Kg
1120 2000 3150 5300 8000 12500
Weight
Kg 0,29
0,61
0,91
1,90
3,70
6,80
Height
mm 110
140
162
200
255
316
Eye Ø
mm 15
28
30
39
51
63
Max hook opening
mm 22
25
27
33
40
51
2133VE
Each 5,16 10,50 13,60 28,30 56,20 124,00
The above-mentioned dimensions may vary at the manufacturer’s discretion.
vuoto
EYEHOISTHOOKS
2133Z
Swivel type, made from special hardened carbon steel. Safety latch.
Painted finish. Marked with load limit in tons.
Load capacity
Kg
800
1000 1600 2000 3200 5000 7500
Weight
Kg 0,69
0,81
1,25
1,45
2,20
4,60
7,40
Height
mm 141
166
200
215
245
312
365
Max hook opening
mm 20
22
26
28
33
43
49
Eye height x width
mm 20x30 32x36 39x43 39x43 40x47 53x64 53x70
2133Z
Each 10,20 12,10 18,40 21,40 26,80 55,40 87,90
The above-mentioned dimensions can vary at the manufacturer’s discretion.
vuoto
EYEHOISTHOOKS
2133ZE
Rotary model, made from GRADE 80 stainless steel, hardened. Safety lock.
Enamel finish. Provides an indication of flow rate in tonnes.
Load capacity
Kg
1120 2000 3150 5300 8000 12500
Weight
Kg 0,30
1,00
1,20
2,20
4,60
7,40
Height
mm 141
190
208
245
310
360
Max hook opening
mm 22
22
25
35
43
50
Eye height x width
mm 26x32 39x44 39x44 44x50 60x64 64x70
2133ZE
Each 7,24 18,40 20,60 34,20 73,20 138,00
The above-mentioned dimensions may vary at the manufacturer’s discretion.
vuoto
EYEHOISTHOOKS
CABLE CLAMPS
2134E
2134G
2134GA
2134GB
2134GC
Prod. SCU
Self-clamping type.
For steel cables, copper cables and steel ropes.
In forged steel, long hardened anti-sliding cheeks.
Art.
2134E
2134G 2134GA 2134GB 2134GC
For cable Ø
mm 1-4
3-8
5-10
8-16
12-26
Max Workload
Kg
500
1000
1700
3000
3500
Breakage load
Kg
1000
1700
3000
5500
6000
Weight
Kg
0,25
0,8
1,1
1,8
3,5
Each 73,80
104,00
120,00
169,00
356,00
vuoto
CABLECLAMPS
2134GD
2134GE
2134GF
Self-clamping type.
For ALUMINIUM cables and ropes.
In forged steel, long hardened anti-sliding cheeks.
Art.
2134GD 2134GE 2134GF
For cable Ø
mm 5,4-8,5
8,6-12
12,1-16
Max Workload
Kg
1000
1700
3000
Breakage load
Kg
1700
3000
5500
Weight
Kg
0,8
1,1
1,8
Each 108,00
125,00
173,00
vuoto
CABLECLAMPS
2134GH
2134GL
2134GP
2134GR
Frog-shaped type.
For steel cables. With hardened knurled cheeks.
Art.
2134GH 2134GL 2134GP 2134GR
For cable Ø
mm 1-4
1-5
1-8
1-12
Each 29,60
34,40
38,40
56,40
vuoto
CABLECLAMPS
