672 / 1378
672
EXPANSION FIXING PLUGS
672
9
Prices in EURO - VAT not included
2814D
Product description as Art. 2814A
With closed eyelet.
Ø
mm
12
14
16
20
Length
mm 40
50
60
75
Screw thread
M.
6
8
10
12
Indivisible pck.
Pz
50
50
25
15
2814D
Per pack 112,00 143,00 96,70 81,90
vuoto
EXPANSIONFIXINGPLUGS
2814E
Product description as Art. 2814A
With open eyelet.
Ø
mm
12
14
16
20
Length
mm 40
50
60
75
Screw thread
M.
6
8
10
12
Indivisible pck.
Pz
50
50
25
15
2814E
Per pack 135,00 149,00 102,00 96,90
vuoto
EXPANSIONFIXINGPLUGS
2814L
Heavy steel type, with anti-rotation lugs, assuresr high tightness and safety. Suitable to fixing in
compact materials such as concrete, stocks, marble, granite, etc.
With threaded bar, nut and washer.
Ø for length
mm
8x55 8x75 8x115 10x65 10x90 10x120 12x75
Thread length
mm 25
35
40
30
32
35
38
Indivisible pck.
Pz
100
100
100
100
50
50
50
Max load on R 250
Kg
350
350
350
500
500
500
800
2814L
Per pack 67,20 73,80 77,20 105,00 57,90 64,90 64,90
Ø for length
mm
12x110 12x145 16x110 16x175 20x170 20x220
Thread length
mm 42
60
50
65
65
85
Indivisible pck.
Pz
50
40
25
20
10
10
Max load on R 250
Kg
800
800
1200 1200 1900 1900
2814L
Per pack 64,90 79,10 78,70 86,80 59,30 71,10
vuoto
EXPANSIONFIXINGPLUGS
2814P
Product description as Art. 2814L
With blind nut and anti-rotation ring.
Ø for length
mm
8x65 8x80 10x75 10x110 12x85 12x120 14x100
Min bore depth
mm 50
50
60
60
70
70
80
Max use thickness
mm 15
30
15
50
15
50
20
Indivisible pck.
Pz
50
50
50
50
50
50
25
Max load on R 250
Kg
350
350
500
500
800
800
1000
2814P
Per pack 113,00 166,00 172,00 239,00 239,00 290,00 204,00
Ø for length
mm
14x130 16x110 16x130
Min bore depth
mm 80
90
90
Max use thickness
mm 50
20
40
Indivisible pck.
Pz
25
25
25
Max load on R 250
Kg
1000 1200 1200
2814P
Per pack 255,00 312,00 364,00
vuoto
EXPANSIONFIXINGPLUGS
PERMANENT MAGNETS
2815A
Prod. SCU
Heat resistance: 450°C
In ALNICO alloy. Magnetic shielding assures a longer lasting magnetic charge. Impact-proof and
heat-resistant outside protection.
Cylindric type with threaded non through hole.
Ø
mm
12,7
17,5
20,6
27
34
35
50
Height
mm 15,8
15,8
19
25,4
20
30
40
Thread bore Ø
M.
4
6
6
6
6
6
8
Magnetic force
Kg
1,5
2,5
4
9,5
6
19
45
2815A
Each 6,14
6,70
7,90 12,80 22,90 26,40 55,90
vuoto
PERMANENTMAGNETS
2815B
Product description as Art. 2815A
Cylindric type with threaded through hole.
Ø
mm
19
28,6
38
Height
mm 8
9,5
11,1
Thread bore Ø
M.
4
6
6
Magnetic force
Kg
2
3,5
15
2815B
Each 7,58
9,34 15,10
vuoto
PERMANENTMAGNETS
2815C
Product description as Art. 2815A
Cylindric type with threadless through hole and slot.
Ø
mm
12,7
19
25,4
31,7
Height
mm 9,5
12,7
15,9
25,4
Bore Ø
mm 4,7
5,4
4,8
7,5
Magnetic force
Kg
1
2
3
6,8
2815C
Each 5,66
7,98 14,10 25,60
vuoto
PERMANENTMAGNETS
