935 / 1378
935
QUADRUPLE V BLOCKS
935
11
Prices in EURO - VAT not included
QUADRUPLE V BLOCKS
4330
2/100
Prod. SCU
Cross-type, in steel. With ground surfaces.
Accuracy: 0.02mm. Sold in two’s only.
Size
42
60
75
100
120
150
Dimensions
mm 42x42 60x60 75X75 100X80 120x90 150x100
4330
Per pair 81,10 113,00 141,00 184,00 236,00 317,00
Size 42 running out of stock.
vuoto
QUADRUPLEVBLOCKS
PRECISION V BLOCKS
4331G
4/1000
Prod. SCU
Cross-type, with clamp for cylinders. In hardened steel, ground and lapped. Two 90° angles.
Accuracy: 0.004mm.
Sold in two’s only.
Size
50
75
100
Dimensions
mm 50x40x40 75x55x55 100x75x75
Ø for cylindrical bodies
mm 5-30
5-50
7-70
4331G
Per pair 194,00
253,00
344,00
vuoto
Wooden case for Art. 4331G.
Size
50
75
100
O4331G
Each 28,90
37,20
58,10
vuoto
PRECISIONVBLOCKS
PRECISION MAGNETIC V BLOCKS
4331GE
5/1000
Orig. Mib
Magnetic type. Switching on and off via switch.
In hardened steel, ground and lapped in PAIRS. Accuracy: 0.005mm.
Particularly suitable for use on machine tools.
Sold in pairs only.
Size
80
100
Dimensions
mm 80x67x96 100x70x96
Ø for cylindrical bodies
mm 6-66
6-72
Prism side magnet force
kN
400
400
Flat side magnet force
kN 1000
1200
4331GE
Per pair 976,00 1.300,00
vuoto
PRECISIONMAGNETICVBLOCKS
4331GM
4/1000
Prod. SCU
Magnetic type. Switching on and off through switch.
In hardened steel, ground and lapped. Accuracy: 0.004mm.
Particularly suitable to be used on machine tools.
In wooden case.
Size
80
100
Dimensions
mm 80x67x96 100x70x96
Ø for cylindrical bodies
mm 6-66
6-70
Prism side magnet force kN 400
400
Flat side magnet force
kN 900
1200
4331GM
Each 653,00
839,00
For single use
PRECISIONMAGNETICVBLOCKS
4331P
1/100
2/100
Magnetic type. Switching on and off through switch.
In hardened steel, ground and finely worked. Accuracy: parallellism 0.01mm, orthogonality
0.02mm, angular 0.02mm.
Particularly suitable to be used on machine tools.
Size
85
130
Dimensions
mm 85x70x85 130x70x85
Ø for cylindrical bodies
mm 50
50
4331P
Each 536,00
645,00
For single use
PRECISIONMAGNETICVBLOCKS
4331T
1/100
Orig. Mib
Magnetic type. Switching on and off via switch.
In hardened steel, ground and finely polished.
Particularly suitable for use on machine tools.
Dimensions 95x70x100mm. For cylindrical bodies Ø 6-66mm. Flat side magnet strength 1000kN.
4331T
Each 143,00
For single use
vuoto
PRECISIONMAGNETICVBLOCKS
