PRECISION V BLOCKS
936
11
Prices in EURO - VAT not included
PRECISION V BLOCKS
4332
2/100
Prod. SCU
Right angle type, in steel.
Ground surfaces.
Accuracy: 0.02mm. Sold in two’s only.
Size
100
150
200
Dimensions
mm 100x45 150X55 200x70
4332
Per pair 91,60 152,00 205,00
vuoto
PRECISIONVBLOCKS
SURFACE PLATES
4335
2/100
Prod. SCU
Heavy finish in special cast iron, indeformable.
Ground surface.
Accuracy according to DIN 876, II Degree
Dimensions
mm
300x200 400x300 500x300 500x400 600x500 800x500
Tolerance ±
mm 0,013 0,014 0,015 0,015 0,016 0,018
Weight
Kg
10
20
28
35
55
80
4335
Each 285,00 456,00 541,00 676,00 971,00 1.400,00
vuoto
SURFACEPLATES
4336
1/100
Product description as Art. 4335
Accuracy according to DIN 876, Grade I
Dimensions
mm
300x200 400x300 500x300 500x400 600x500 800x500
Tolerance ±
mm 0,0065 0,007 0,0075 0,0075 0,008 0,009
Weight
Kg
10
20
28
35
55
80
4336
Each 320,00 516,00 654,00 768,00 1.150,00 1.600,00
vuoto
SURFACEPLATES
SETS OF GAUGES BLOCKS
4339GA
4339GB
4339GC
Orig. MIB - Art. 06062000-06062001-06062002
In high resistance special steel, accuracy according to DIN EN ISO 3650, for control stations and
workshop. Lapped finish. Individual identification number and certificate of inspection. SIT or DKD
certification available on request. Supplied in wooden case.
The set consists of 32pcs. having following dimensions:
No.1 x 1.005 mm
No.9 x 1.01 to 1.09mm (progression 0.01mm)
No.9 x 1.10 to 1.90mm (progression 0.10mm)
No.9 x 1 to 9mm (progression 1mm)
No.1 for each 10 - 20 - 30 - 50.
Accuracy grade 0.
4339GA
Each 474,00
Product description as Art. 4339GA
Accuracy grade 1.
4339GB
Each 287,00
Product description as Art. 4339GA
Accuracy grade 2.
4339GC
Each 187,00
Loose verification blocks, level 0 - 1 available on request.
SETSOFGAUGESBLOCKS
4340GA
4340GB
4340GC
Orig. MIB - Art. 06062005-06062006-06062007
In high resistance special steel, accuracy according to DIN EN ISO 3650, for control stations and
workshop. Lapped finish. Individual identification number. SIT or DKD certification available on
request. Supplied in wooden case. 47-pcs. set having following dimensions::
1 x 1.005mm
20 x 1.01 to 1.20 mm (progression 0.01mm)
7 x 1.30 to 1.90mm (progression 0.10mm)
9 x 1 to 9mm (progression 1mm)
10 x 10 to 100 mm (progression 10mm).
Accuracy grade 0.
4340GA
Each 718,00
Product description as Art. 4340GA
Accuracy grade 1.
4340GB
Each 431,00
Product description as Art. 4340GA
Accuracy grade 2.
4340GC
Each 287,00
Loose verification blocks, level 0 - 1 available on request.
