SETS OF GAUGES BLOCKS
937
11
Prices in EURO - VAT not included
4341GA
4341GB
4341GC
Orig. MIB - Art. 06062010-06062011-06062012
In high resistance special steel, accuracy according to DIN EN ISO 3650, for control stations and
workshop. Lapped finish. Individual identification number and certificate of inspection. SIT or DKD
certification available on request. Supplied in wooden case.
The set consists of 87pcs. having following dimensions:
No.9 x 1.001 to 1.009mm (progression 0.001mm)
No.49 x 1.01 to 1.49mm (progression 0.01mm)
No.19 x 0.5 to 9.5mm (progression 0.50mm)
No.10 x 10 to 100mm (progression 10mm).
Accuracy grade 0.
4341GA
Each 1.010,00
vuoto
Product description as Art. 4341GA
Accuracy grade 1.
4341GB
Each 660,00
vuoto
Product description as Art. 4341GA
Accuracy grade 2.
4341GC
Each 416,00
Loose verification blocks, level 0 - 1 and an assortment of 103 pcs, level 0-1-2 available on request.
vuoto
SETSOFGAUGESBLOCKS
4345GA
4345GB
Orig. MIB - Art. 06061086-06061087
Made from high-resistance ceramic with accuracy according to DIN EN ISO 3650, suitable for use
in a metrological room and for control of measuring instruments, etc. Lapped finish. With
individual identification number and inspection certificate. SIT or DKD certification available upon
request. In a wooden box.
Comprises 47 pieces in the following sizes:
1 pcs./1.005 mm
20 pcs./from 1.01 to 1.20 mm (steps of 0.01mm)
7 pcs./from 1.30 to 1.90 mm (steps of 0.10mm)
9 pcs./from 1 to 9 mm (steps of 1mm)
10 pcs./from 10 to 100 mm (steps of 10mm).
Accuracy grade 0.
4345GA
Each 2.880,00
vuoto
Product description as Art. 4345GA
Accuracy grade 1.
4345GB
Each 2.390,00
vuoto
SETSOFGAUGESBLOCKS
PLUG GAUGES
4350GA
Orig. MIB
Plug gauge according to DIN 2245, PASS-NOT PASS, smooth, in special hardened steel,
tolerance 7h.
Nominal measure Ø
mm
2
3
4
5
6
7
8
9
10
11
Supplier code
08086001 08086002 08086004 08086005 08086006 08086007 08086008 08086009 08086010 08086011
4350GA
Each 28,70
28,70
28,70
28,70
30,20
30,20
30,20
30,90
30,90
30,90
Nominal measure Ø
mm
12
13
14
15
16
17
18
19
20
21
Supplier code
08086012 08086013 08086014 08086015 08086016 08086017 08086018 08086019 08086020 08086021
4350GA
Each 30,90
30,90
30,90
30,90
32,30
32,30
34,50
34,50
37,30
37,30
Nominal measure Ø
mm
22
23
24
25
26
27
28
30
32
33
Supplier code
08086022 08086023 08086024 08086025 08086026 08086027 08086028 08086030 08086032 08086033
4350GA
Each 37,30
37,30
37,30
37,30
43,10
43,10
43,10
44,50
45,90
45,90
Nominal measure Ø
mm
34
35
36
38
40
42
44
45
46
48
Supplier code
08086034 08086035 08086036 08086038 08086040 08086042 08086044 08086045 08086046 08086048
4350GA
Each 45,90
51,70
54,60
54,60
57,40
63,20
63,20
86,10
86,10
86,10
Nominal measure Ø
mm
50
52
55
58
60
62
65
68
70
72
Supplier code
08086050 08086052 08086055 08086058 08086060 08086062 08086065 08086068 08086070 08086072
4350GA
Each 86,10
97,60
97,60
97,60
104,00
104,00
130,00
130,00
130,00
130,00
Nominal measure Ø
mm
75
78
80
82
85
88
90
92
95
98
Supplier code
08086075 08086078 08086080 08086082 08086085 08086088 08086090 08086092 08086095 08086098
4350GA
Each 165,00
165,00
173,00
173,00
187,00
187,00
201,00
201,00
230,00
230,00
Nominal measure Ø
mm
100
Supplier code
08086100
4350GA
Each 244,00
vuoto
PLUGGAUGES
