INDICATOR STANDS
950
11
Prices in EURO - VAT not included
INDICATOR STANDS
4421
Orig. MIB - Art. 06070000
Universal type with sliding column on base.
For comparators with coupling Ø 8mm.
Ground parallel surfaces and chrome finished support rods.The horizontal arm swivels and tilts.
Total height 270mm. Column diameter 14mm. Horizontal arm length 235mm, diameter 12mm.
Base dimensions: length 220mm, width 58mm, height 35mm.
Without dial indicator.
4421
Each 63,20
vuoto
INDICATORSTANDS
4421A
Prod. SCU - Orig. Käfer
Magentic model. Small dimensions, handy and easy to use. Flat base with 2 permanent active
magnetics. Base dimensions: length 73mm, width 38mm, height 11mm. Horizontal arm, 360°
swiveling and 30° vertically tilting approx.
Total height 46m. Length of swivel arm up to holder opening 35mm. Holder opening for dial
indicators Ø 8mm.
Without dial indicator.
Magnet force
N 180
4421A
Each 114,00
For similar model, but with prism-shaped base see Art. 4414 GS.
INDICATORSTANDS
4421B
Orig. MIB - Art. 06071010
Magnetic type. Standard machining, prismatic base.
Magnetic adhesion with lever insertion and detachment.
Base dimensions: length 60mm, width 50mm, height 55mm.
The horizontal arm swivels and tilts, with micrometer adjustment.
Total height 231mm. Column diameter 12mm.
Horizontal arm length 150mm, diameter 10mm.
For comparators with coupling Ø 8mm.
Without dial indicator.
Magnet force
N 600
4421B
Each 26,60
INDICATORSTANDS
4421BE
Orig. MIB - Art. 06071005
Magnetic model. Implementation strengthened.
Magnetic-mount adhesion and detachment.
Dimensions: length. 60 mm, min. 50 mm, alt. 55 mm.
The horizontal arm can be rotated and tilted, with micrometric adjustment.
Total height: 281 mm. Column diameter mm 16.
Horizontal arm length 200 mm, diameter 12 mm.
For comparators with 8 mm diameter.
Without comparator.
Magnet force
N 600
4421BE
Each 33,10
INDICATORSTANDS
4421C
Orig. MIB - Art. 06071025
Magnetic type. Heavy-duty machining, prismatic base.
Very strong magnetic adhesion with lever insertion and detachment.
Base dimensions: length 63mm, width 50mm, height 55mm.
The horizontal arm swivels and tilts, with micrometer adjustment.
Total height 290mm. Column diameter 16mm.
Horizontal arm length 250mm, diameter 16mm.
For comparators with coupling Ø 8mm.
Without dial indicator.
Magnet force
N 800
4421C
Each 76,10
vuoto
INDICATORSTANDS
4421ET
Prod. SCU
Magnetic model. Precision fine finish, with central tensioning system, prism-shaped base.
High magnetic force with switch on/off.
Chromed arms and micrometric adjustment.
Base dimensions: length 40mm, width 30mm, height 35mm.
Total height 210mm.
Active radius 150mm.
Holder opening for dial indicators Ø 8mm.
Without dial indicator.
Magnet force
N 200
4421ET
Each 77,00
