HAND TACHOMETERS
956
11
Prices in EURO - VAT not included
HAND TACHOMETERS
4430GB
Prod. SCU
2nd revolutions 400 ÷ 5000 / m 40 ÷ 500 | 3rd revolutions 4000 ÷ 50000 / m 400 ÷ 5000
Provided with roller for finding the number of metres by dividing the surface speed by 10. Anti-
magnetic, handy and easy to use.
Do not lubricate.
Supplied with the following accessories:
1 rubber pointer, taper pointed, with coupling support.
1 rubber pointer, big funnel.
1 roller with flat strip and throat for cord, for surface speed and no. of revolutions for shaft without
hub.
4 soft rubber pointers, taper pointed, interchangeable.
Holding case.
4430GB
Each 511,00
vuoto
HANDTACHOMETERS
DIGITAL ELECTRONIC TACHOMETERS
4430GCA
Prod. SCU
Direct reading on display (5 digits). Model with optimal quality/price ratio.
Good precision equipment (±0.02% +1 digit), user friendly for measuring without mechanic
contact.
Field of measurement: 1 to 60000 revi/min.
Apply self-adhesive reflective surface on the rotating part (standard supplied).
Max. measuring distance: 0.45m.
ncorporated memory for recalling the latest reading.
Automatic stop after 30 sec. from the latest measurement. Indicator of discharged batteries.
Operated by 2 alkaline batteries AA.
4430GCA
Each 212,00
vuoto
Set of self-adhesive reflective strips (10 pcs.), for Art. 4430 GCA - 4430 GD - 4430 GF..
O4430GCA
Per set
27,40
vuoto
DIGITALELECTRONICTACHOMETERS
4430GD
Professional model, direct reading on display (5 digits), casing covered with rubbery material for
high protection and a more comfortable use.
Good precision equipment (±0.02% +1 digit), user friendly for measuring without mechanic
contact.
Field of measurement: 1 to 99999 revi/min.
Apply self-adhesive reflective surface on the rotating part (standard supplied).
Max. measuring distance: 0.60m.
Incorporated memory for recalling the latest, the max., the min. and the average reading.
Automatic stop after 30 sec. from the latest measurement. Indicator of discharged batteries.
Operated by 2 alkaline batteries AA. Supplied in case.
4430GD
Each 309,00
For additional reflective strips see Art. O4430 GCA.
vuoto
DIGITALELECTRONICTACHOMETERS
4430GE
Double function for contact measurement or infrared beams measurements (laser beam).
Particularly indicated for checks and measurements on moving parts, motors, operating
machines, etc.
Direct reading on display (5 digits).
High precision equipment (± 0.05% +1 digit), easy to use.
Field of measurement with contact: 5 - 19999 rev./min.
Field of measurement with infrared: 5 - 99999 rev./min.
For infrared measurements, apply the reflective strap (1 strap of 60cm included in the equipment)
on the moving part.
For contact measurements, apply the supplied accessories (2 pointers and 1 roller for surface
speeds).
Measuring distance with laser ray fro 50 to 500 mm.
Incorporated memory for recolling the last reading.
Circuit manufactured with an exclusive microprocessor LSI and quartz time base.
Operated by 4 alkaline batteries (AA)
Dimensions: 210x74x37mm.
Holding case.
4430GE
Each 305,00
Spare parts supplied on request.
vuoto
Self-adhesive reflective strips, 60cm, for Art. 4430 GE.
O4430GE
Each 13,90
vuoto
DIGITALELECTRONICTACHOMETERS
