INDICATOR STANDS
951
11
Prices in EURO - VAT not included
4421F
Orig. MIB - Art. 06071002
Magnetic model. Precision fine finish, with central tensioning system, prism-shaped base.
Big magnetic force with switch on/off.
Chromed arms and micrometric adjustment.
Base dimensions: length 65mm, width 50mm, height 55mm.
Total height 380mm.
Range of action 310mm.
Holder opening for dial indicators Ø 8mm.
Without dial indicator.
Magnet force
N 600
4421F
Each 53,10
vuoto
INDICATORSTANDS
4421GA
Prod. SCU
Professional/industrial model with magnetic base. High precision, fine finish, very stable and
sturdy, with central tensioning system. Chromed arms with precision articulations, guided travel
and micrometric adjustment.
Round base dimensions 40mm x height 30mm. Active radius 200mm. Total height 335mm.
Holder opening for dial indicators Ø 8mm and indicator/pointers with dovetail clamp.
Without dial indicator.
Magnet force
N 300
4421GA
Each 340,00
vuoto
INDICATORSTANDS
4421GB
Professional/industrial model with magnetic base and switch on/off, prism-shaped base. High
precision, fine finish, very stable and sturdy, with central tensioning system.
Chromed arms with precision articulations, guided travel and micrometric adjustment.
Holder opening for dial indicators Ø 8mm and indicator/pointers with dovetail clamp.
Without dial indicator.
Action range
mm
200
280
420
620
Overall height
mm 310
390
570
630
Prismatic base dimensions mm 60x50x55h 60x50x55h 75x50x55h 120x60x52h
Magnet force
N
750
750
1000
1500
4421GB
Each 373,00
431,00
766,00
1.210,00
Dimensions 620mm with flat base, instead of prism-shaped base.
vuoto
INDICATORSTANDS
4421L
Orig. MIB - Art. 06071015
Magnetic rod, fully swivelling in any position.
Big magnetic force with switch on/off.
Base dimensions: length 65mm, width 50mm, height 55mm.
Total height 370mm.
Holder opening for dial indicators Ø 8mm.
Without dial indicator.
Magnet force
N 600
4421L
Each 56,10
vuoto
INDICATORSTANDS
PRECISION DIAL BENCH GAUGES
4421R
Prod. SCU
With fixed round base, for verification in hardened steel, ground and lapped.
Shiftable horizontal arm, vertical column in hardened ground steel.
Base diameter 75mm. Working height 180mm. Total height 260mm.
Column diameter 25mm. Holder opening for dial indicators Ø 8mm.
Without dial indicator.
4421R
Each 240,00
vuoto
PRECISIONDIALBENCHGAUGES
