960 / 1378
960
STROKE COUNTERS
960
11
Prices in EURO - VAT not included
4443GD 1
4443GS 1
Prod. SCU
Quick zero-setting through upper lever.
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Max. stroke number approx 700 per min. Body in die-cast zama, sturdy construction.
Digit number 5. Digit height 6mm. Dimensions 93x47x32mm.
Art.
4443GD 1 4443GS 1
Rotation
right
left
Each 126,00
126,00
vuoto
STROKECOUNTERS
METER COUNTERS
4443GT
Prod. SCU
Electric SUBTRACTING system.
Body in die-cast aluminium, metal internal workings and self-lubricating synthetic material, speed
1000 strokes per min.
Right shaft side, right rotation.
Digit number 4. Digit height 8mm. Dimensions 115x95x50mm.
Contact range 1 AMP 24V d.c.
4443GT
Each 162,00
vuoto
METERCOUNTERS
METER COUNTERS
4444GD
4444GS
Prod. SCU - Orig. IVO
Adds in one direction. Subtracts in the opposite direction. 5 rev. = 1 metre.
For wheels circumfurence 200mm.
Max speed 200 metre per min.
Zerosetting by means of movable lever.
Counts up to 9999.9 metres. Shaft diameter 4mm.
Digits height 4.5mm. Base dimensions 80x48mm.
Right shaft rotation, without wheel.
4444GD
Each 153,00
vuoto
Product description as Art. 4444GD
Left shaft rotation, without wheel.
4444GS
Each 153,00
For wheels see Art. 4452 GA-B-C
vuoto
METERCOUNTERS
4445GA
4445GB
Prod. SCU
Adds in one direction. Subtracts in the opposite direction. 5 rev. = 1 metre.
For wheels circumference 200mm.
Max speed 500 metre per min.
Zero-setting by means of movable lever.
Counts up to 9999.9 metres. Shaft diameter 6mm.
Body in die-cast zama, sturdy construction.
Digit number 5. Digit height 6mm. Dimensions 93x47x32mm.
Without wheel.
Art.
4445GA 4445GB
Rotation
right
left
Each 126,00 126,00
vuoto
For wheels see Art. 4452 GL - GM.
METERCOUNTERS
4445GD
4445GS
4446GD
4446GS
Prod. SCU - Orig. IVO
Adds in one direction. 2 rev. = 1 metre.
For wheels circumfurence 500mm. Max speed apporx. 100 metre per min.
Zerosetting by means of removable key.
Counts up to 999,999.9 metres.
Shaft diameter 7mm.
Digits height 7mm. Base dimensions 120x64mm.
Without hinge and without wheels.
Art.
4445GD 4445GS
Rotation
right
left
Each 186,00
203,00
vuoto
Product description as Art. 4445GD
With hinge, without wheel.
Art.
4446GD 4446GS
Rotation
right
left
Each 186,00
186,00
For wheels see Art. 4453 A-B-C.
vuoto
