METER COUNTERS
961
11
Prices in EURO - VAT not included
METERCOUNTERS
4448GD
4448GS
Adds in one direction. Subtracts in the opposite direction. 2 rev. = 1 metre.
For wheels circumference 500mm.
Max speed 200 metre per min.
Instantaneous zero-setting by means of lever movable on both sides.
Counts up to 9,999.9 metres.
Shaft diameter 7mm.
Digit height 7mm. Base dimensions 120x64mm.
Without wheel.
Art.
4448GD 4448GS
Rotation
right
left
Each 242,00
242,00
For wheels see Art. 4453 A-B-C.
vuoto
METERCOUNTERS
4449GD
4449GS
Prod. SCU
Adds in one direction. Subtracts in the opposite direction. 2 rev. = 1 metre.
For wheels circumference 500mm.
Max speed 500 metre per min.
Quick zero-setting by means of lever movable on both sides.
Counts up to 9,999.9 metres.
Shaft diameter 8mm.
Body in die-cast aluminium, sturdy construction.
Digit number 6. Digit height 7mm. Dimensions 130x67x53mm.
Without wheel.
Art.
4449GD 4449GS
Rotation
right
left
Each 198,00 198,00
vuoto
For wheels see Art. 4453 L - M.
METERCOUNTERS
METER COUNTERS
4450GD
4450GS
Prod. SCU - Orig. IVO
Electric SUBTRACTING system.
For wheel circumference 500mm.
To preset the desired value, use the 5 buttons.
The meter counter subtracts from the preset value until it reaches zero, when it disengages an
electric contact. Automatic disengagement at zero.
See Art. 4437 G for the procedure of value presetting.
Zerosetting lever movable on both sides. To repeat the same value, just push the lever.
2 rev. = 1 metre. Counts up to 9,999.9m. Max metre per min. 250.
For wheel circumference 500mm..
For alternate current up to V 220.
Without wheel.
Art.
4450GD 4450GS
Rotation
right
left
Ciphers height
mm 7
7
No. of ciphers
5
5
Base dimensions
mm 142x88
142x88
Each 844,00
923,00
For wheels see Art. 4453 A-B-C.
vuoto
METERCOUNTERS
4451GD
4451GS
Prod. SCU
Electrical ADDITIONING system.
For wheel circumference 500mm. Max speed 500 m/min.
Quick zero-setting by means of lever. Body in die-cast aluminium, sturdy construction. Upon
reach of the preset value, a micro commuter is activated according to basic operation settings.
Counts up to 9,999.9 metres. Shaft diameter 8m. 2 rev. = 1m.
Digit number 5. Digit height 8mm. Dimensions 130x87x57mm.
Contact range 1 A 24 V d.c.
Without wheel.
Art.
4451GD 4451GS
Rotation
right
left
Each 416,00
416,00
vuoto
For wheels see Art. 4453 L - M.
