1205
Prices in EURO - VAT not included
1205
MILLS FOR SCREW SEATS WITH INTERCHANGEABLE GUIDES
13
8927GB
HSS
Orig. Dürr
Interchangeable guides DIN 373 for mills Art. 8927 GA.
HSS.
Ø screw x Ø guide
M x mm
4x4,3
4x4,5
5x4,2
5x5,3
Guide Ø drive
mm
2,5
2,5
3,6
3,6
For mills Art.
8927GA 4
8927GA 4
8927GA 5-6 8927GA 5-6
8927GB
Each
24,70
24,70
24,70
24,60
Ø screw x Ø guide
M x mm
5x5,5
6x5
6x6,4
6x6,6
Guide Ø drive
mm
3,6
3,6
3,6
3,6
For mills Art.
8927GA 5-6 8927GA 5-6 8927GA 5-6 8927GA 5-6
8927GB
Each
24,60
24,70
24,60
24,70
Product running out of stock
vuoto
MILLSFORSCREWSEATSWITH INTERCHANGEABLEGUIDES
COUNTERBORES FOR TAPERED-HEAD SCREW SEATS (PASSING-THROUGH SCREWS)
8928G
HSS
Orig. Dürr - Art. 211-51
HSS.
For creating the seat to the tapered head of internal hexagonal passing-through screws.
For iron and high-resistance steel.
Morse taper shank. FINE tolerance.
For screws
M.
10
12
14
16
18
20
22
24
Cutting edges Ø
mm 18
20
24
26
30
33
36
40
Guide Ø
mm 10,5 13
15
17
19
21
23
25
Overall length
mm 150 150 160 190 190 190 205 205
Drive
C.M.
2
2
2
3
3
3
3
3
8928G
Each 62,10 65,50 77,20 87,40 103,00 121,00 163,00 172,00
vuoto
COUNTERBORESFORTAPERED-HEADSCREWSEATS (PASSING-THROUGHSCREWS)
8929G
HSS
HSS.
For creating the seat to the tapered head of internal hexagonal passing-through screws.
For iron and high-resistance steel.
Morse taper shank. MEDIUM tolerance.
For screws
M.
10
12
14
16
18
20
22
24
Cutting edges Ø
mm 18
20
24
26
30
33
36
40
Guide Ø
mm 11 13,5 15,5 17,5 20
22
24
26
Overall length
mm 150 150 160 190 190 190 205 205
Drive
C.M.
2
2
2
3
3
3
3
3
8929G
Each 58,70 62,10 73,40 82,60 97,20 115,00 154,00 162,00
vuoto
COUNTERBORESFORTAPERED-HEADSCREWSEATS (PASSING-THROUGHSCREWS)
COUNTERBORES FOR TAPERED-HEAD SCREW SEATS (SCREWS TO THREAD)
8930G
HSS
Orig. Dürr - Art. 211-51
HSS.
For creating the seat to the tapered head of internal hexagonal screws to thread.
For iron and high-resistance steel.
Morse taper shank.
For screws
M.
10
12
14
16
18
20
22
24
Cutting edges Ø
mm 18
20
24
26
30
33
36
40
Guide Ø
mm 8,5 10,2 12
14 15,5 17,5 19,5 21
Overall length
mm 150 150 160 190 190 190 205 205
Drive
C.M.
2
2
2
3
3
3
3
3
8930G
Each 67,40 70,10 83,40 93,40 112,00 132,00 173,00 197,00
vuoto
COUNTERBORESFORTAPERED-HEADSCREWSEATS (SCREWSTOTHREAD)
MILLS FOR SCREW SEATS WITH INTERCHANGEABLE GUIDES
8931GA
HSS
Orig. Dürr - Art. 214-51
HSS-DIN 375.
For creating the seat of the cylindrical head of through screws or screws to thread according to
DIN. With front hole and lock screw for the different guides. With one mill only, by replacing the
interchangeable guides, it is possible to countersink holes of different diameters.
For iron, high-resistance steel, aluminium, cast iron, etc.
Morse Taper Shank.
SUPPLIED WITHOUT GUIDES (For guides see Art. 8931 GB).
For screws
M.
10
Mill cutting edges Ø
mm 18
Ø bore conn. guide
mm 5
C.M. drive
C.M.
2
Overall length without
guide
mm 140
8931GA
Each 95,10
Product running out of stock
vuoto
MILLSFORSCREWSEATSWITH INTERCHANGEABLEGUIDES
