1208
Prices in EURO - VAT not included
1208
HAND REAMERS WITH CYLINDRICAL SHANK
13
HAND REAMERS WITH CYLINDRICAL SHANK
8964
HSS
Prod. SCU
HSS – DIN 206B.
Ground helicoidal cutting edges.
With drive board and cylindrical shank.
Tolerance H7.
Ø
mm
5
5,5
6
6,5
7
7,5
8
8,5
9
9,5
10 10,5 11 11,5 12
Cutting edge length
mm 44
47
47
50
54
54
58
58
62
62
66
66
71
71
76
Overall length
mm 87
93
93 100 107 107 115 115 124 124 133 133 142 142 152
Square drive
mm 4
4,5 4,5
5
5,6 5,6 6,3 7,1 7,1 7,1
8
8
9
10
10
8964
Each 22,50 27,10 24,30 31,10 27,20 31,90 29,60 33,80 32,60 35,10 36,10 38,10 48,50 41,70 53,30
Ø
mm
12,5 13
14
15
16
17
18
19
20
21
22
23
24
25
26
Cutting edge length
mm 76
76
81
81
87
87
93
93 100 100 107 107 115 115 115
Overall length
mm 152 152 163 163 177 177 188 188 201 201 215 215 231 231 231
Square drive
mm 10
10 11,2 11,2 12,5 12,5 14
14
16
16
18
18
20
20
20
8964
Each 54,10 58,10 65,10 71,10 79,90 81,10 82,30 86,40 102,00 103,00 114,00 121,00 141,00 141,00 157,00
Ø
mm
27
28
30
Cutting edge length
mm 124 124 124
Overall length
mm 247 247 247
Square drive
mm 22,4 22,4 22,4
8964
Each 169,00 187,00 206,00
HANDREAMERSWITHCYLINDRICALSHANK
8965G
HSS
Orig. Dürr - Art. 313-21
HSS – DIN 206B.
Ground helicoidal cutting edges (1.5 – 1.6 – 1.8mm with straight cutting edges).
With DIN 10 drive board and cylindrical shank.
Tolerance H7.
Ø
mm
1,5
1,6*
1,8*
2
2,2
2,5
2,8*
3
3,5
4
4,5
5
Cutting edge length
mm 20
21
23
25
27
29
31
31
35
38
41
44
Overall length
mm 41
44
47
50
54
58
62
62
71
76
81
87
Square drive
mm 1,12
1,25
1,4
1,6
1,8 2 (2,10)
2,24 2,24 (2,40) 2,8 (2,7) 3,15 (3) 3,55 (3,4) 4 (3,8)
8965G
Each 44,80 43,40 43,40 32,70 47,70 37,30 49,90
31,10
51,10 26,40 37,90 30,50
Ø
mm
5,5
6
7
8
9
10
11
12
13
14
15
16
Cutting edge length
mm 47
47
54
58
62
66
71
76
76
81
81
87
Overall length
mm 93
93
107
115
124
133
142
152
152
163
163
175
Square drive
mm 4,5 (4,3) 4,5 (4,9) 5,6 (5,5) 6,3 (6,2) 7,1 (7,0)
8
9
10 (9)
10 11,2 (11) 11,2 (12) 12,5 (12)
8965G
Each 41,40 29,90 35,60 35,00 43,10 38,50 53,40
45,40
74,60 72,30 82,70 80,40
Ø
mm
17
18
19
20
22
24
25
26*
28
30
Cutting edge length
mm 87
93
93
100
107
115
115
115
124
124
Overall length
mm 175
188
188
201
215
231
231
231
247
247
Square drive
mm 12,5 (13) 14 (14,5) 14 (14,5)
16
18
20 (18)
20
20 22,4 (22) 22,4 (24)
8965G
Each 91,80 105,00 113,00 99,90 127,00 150,00 138,00 182,00 207,00 194,00
When the stocks will be run out we will provide the same reamers marked Hartner (Art. 88310).
The sizes of the square drives in parentheses refer to Article. Orig. Hartner.
* Sizes running out of stock
HANDREAMERSWITHCYLINDRICALSHANK
MACHINE TAPER PIN REAMERS
8968G
HSS
Orig. Dürr - Art. 324-31
HSS – DIN 2179.
Ground, helicoidal, 45° left-hand cutting edges.
Taper 1:50. Cylindrical shank.
Tolerance H7.
Rated Ø
mm
2
2,5 3
4
5
6
8
10 12
Min Ø
mm 1,9 2,4 2,9 3,9 4,9 5,9 7,9 9,9 11,8
Max Ø
mm 2,86 3,36 4,06 5,26 6,36 8 10,8 13,4 16
Cutting edge length
mm 48 48 58 68 73 105 145 175 210
Overall length
mm 86 86 100 112 122 160 207 245 290
Drive Ø
mm 3,15 3,15 4
5 6,3 8
10 12,5 16
8968G
Each 48,30 58,10 53,10 54,70 56,40 66,10 98,20 126,00 160,00
MACHINETAPERPINREAMERS
