1209
Prices in EURO - VAT not included
1209
MACHINE REAMERS
13
MACHINE REAMERS
8970G
HSS-E
Orig. Dürr - Art. 314-21
COBALT HSS-E – DIN 212.
Ground helicoidal cutting edges. Left-hand spiral flute. For right-hand cutting.
Cylindrical shank. Tolerance H7. Long pattern.
Ø
mm
1,5 1,8
2
2,2 2,5 2,8
3
3,2 3,5
4
4,5
5
5,5
6
6,5
7
7,5
Cutting edge length mm 8
10 11 12 14 15 15 16 18 19 21 23 26 26 28 31 31
Overall length
mm 40 46 49 53 57 61 61 65 70 75 80 86 93 93 101 109 109
Drive Ø
mm 1,5 1,8
2
2,2 2,5 2,8
3
3,2 3,5
4
4,5
5
5,6 5,6 6,3 7,1 7,1
8970G Each 17,40 25,60 15,10 23,20 16,40 25,60 13,50 23,90 18,40 16,60 18,50 17,10 23,10 18,10 24,10 21,50 31,30
Ø
mm
8
8,5
9
9,5 10 10,5 11 11,5 12 13 14 15 16 17 18 19 20
Cutting edge length mm 33 33 36 36 38 38 41 41 44 44 47 50 52 54 56 58 60
Overall length
mm 117 117 125 125 133 142 142 142 151 151 160 162 170 175 182 189 195
Drive Ø
mm 8
8
9
9
10 10 10 10 10 10 12,5 12,5 12,5 14 14 16 16
8970G Each 22,30 34,30 27,50 35,80 26,40 62,50 41,50 54,30 38,50 43,70 44,50 46,10 47,50 63,30 61,00 75,40 65,60
When the stocks will be run out we will provide the same reamers marked Hartner (Art. 88304-88306).
MACHINEREAMERS
8971G
HSS-E
COBALT HSS-E – DIN 212.
Ground helicoidal cutting edges. Left-hand spiral flute. For right-hand cutting.
Cylindrical shank. Tolerance H7.
Type
2
3
4
5
6
6L
8
Ø
mm 2
3
4
5
6
6
8
Cutting edge length
mm 11
15
19
23
26
26
33
Max boring length
mm 45
65
70
80
90
210
115
Drive Ø
mm 2
3
4
5
6
6
8
8971G
Each 93,40 72,40 74,10 75,70 77,30 184,00 80,50
Type
8L
10
10L
12
Ø
mm 8
10
10
12
Cutting edge length
mm 33
38
38
44
Max boring length
mm 200
140
200
160
Drive Ø
mm 8
10
10
12
8971G
Each 187,00 93,40 190,00 105,00
vuoto
MACHINEREAMERS
8971R
HARTMETALL
Prod. SCU
SOLID CARBIDE K 10 - DIN 212.
Ground, helicoidal cutting edges. Left-hand spiral flute. For right-hand cutting. Cylindrical shank.
Tolerance H7.
Ø
mm
2
2.5
3
3.5
4
4.5
5
5.5
6
Cutting edge length
mm 11 14 15 18 19 21 23 26 26
Overall length
mm 50 57 60 70 75 80 93 93 93
Drive Ø
mm 2
2.5
3
3.5
4
4.5
5
5.5
6
8971R
Each 25,70 23,40 25,70 29,70 33,30 38,50 45,10 51,50 52,90
Ø
mm
6.5
7
8
9
10 11 12 13
Cutting edge length
mm 28 31 33 36 38 41 44 44
Overall length
mm 100 109 117 125 135 140 150 150
Drive Ø
mm 6.5
7
8
9
10 11 12 13
8971R
Each 60,10 68,20 80,20 92,10 115,00 145,00 173,00 201,00
MACHINEREAMERS
8972G
HARTMETALL
Orig. Dürr - Art. 314-23
SOLID CARBIDE K 10 tipped cutting edges – Similar to DIN 8093.
Ground, helicoidal cutting edges. Left-hand spiral flute. For right-hand cutting. Cylindrical shank.
Tolerance H7.
Ø
mm
5
6
7
8
11
12
14
20
Cutting edge length
mm 23
26
31
33
41
44
47
60
Overall length
mm 86
93
109 117 142 151 160 195
Drive Ø
mm 5
5,6
7,1
8
10
10 12,5 16
8972G
Each 105,00 105,00 108,00 107,00 159,00 171,00 188,00 266,00
Product running out of stock
MACHINEREAMERS
8974G
HSS-E
Orig. Dürr - Art. 314-31
COBALT HSS-E – DIN 212. 45° left-hand spiral flute. For right-hand cutting.
For passing-through holes only, frontal chip discharge.
Cylindrical shank. Tolerance H7.
Ø
mm
2,5
3
3,5
4
4,5
6
7
9
Cutting edge length
mm 14
15
18
19
21
26
31
36
Overall length
mm 57
61
70
75
80
93
109 125
Drive Ø
mm 2,5
3
3,5
4
4,5
5,6
7,1
9
8974G
Each 30,20 34,10 39,70 34,10 39,70 35,90 41,50 54,70
Ø
mm
10
12
13
16
18
19
Cutting edge length
mm 38
44
44
52
56
58
Overall length
mm 133 151 151 170 182 189
Drive Ø
mm 10
10
10 12,5 14
16
8974G
Each 51,10 62,30 86,80 84,90 116,00 133,00
Product running out of stock
