DRILLS FOR METALS, RIGHT-HAND ROTATION
1126
13
Prices in EURO - VAT not included
8463G
HSS-E
TIN
Orig. Hartner
Spiral flute length according to DIN 338. Type FU 500 DZ. COBALT HSS-E+TIN. Cutting angle
118°. SHORT pattern.
Particular 4 facet grinding and special web thinning for low turning moments, higher drilling
parameters and good finishing of the hole surface.
For alloy and unalloyed steel up to R 850 N/sqmm, steel for hot/cold working, bearing steel,
stainless steel, non-ferrous metals, cast iron and plastic materials.
Cylindrical shank. TIN treatment.
Ø
mm
2
2,5
3
3,3 3,5
4
4,2 4,5 5
5,5
6
6,5 6,8
7
7,5
8
8,5
Overall length
mm 49 57 61 65 70 75 75 80 86 93 93 101 109 109 109 117 117
Helix length
mm 24 30 33 36 39 43 43 47 52 57 57 63 69 69 69 75 75
Drive Ø
mm 2
2,5
3
3,3 3,5
4
4,2 4,5 5
5,5
6
6,5 6,8
7
7,5
8
8,5
Drive length
mm -
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Supplier code
84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802
8463G
Each 7,02 7,20 7,68 8,54 9,20 9,48 9,76 10,30 10,90 13,10 13,20 15,80 18,10 18,10 18,80 21,40 21,80
Ø
mm
9
9,5 10 10,2 10,5 11 11,5 12 13 14 15 16 17 18 19 20
Overall length
mm 125 125 133 133 133 142 142 151 151 160 169 172 181 184 188 191
Helix length
mm 81 81 87 87 87 94 94 101 101 108 109 112 115 118 122 125
Drive Ø
mm 9
9,5 10 10,2 10,5 11 11,5 12 13 14 16 16 20 20 20 20
Drive length
mm -
-
-
-
-
-
-
-
-
-
48 48 50 50 50 50
Supplier code
84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84801 84801 84801 84801 84801 84801
8463G
Each 24,70 25,60 28,50 33,20 33,20 34,20 38,40 40,30 45,10 54,10 267,00 286,00 302,00 331,00 376,00 390,00
DRILLSFORMETALS,RIGHT-HANDROTATION
8464G
HSS-E
FIRE
Orig. Hartner - Art. 84507
Spiral flute length according to DIN 338. Type FN 500 DZ. COBALT HSS-E + FIRE. Cutting angle
130°. SHORT pattern. High-performance drills, excellent heat resistance, wide slots. Produced by
using the powder-sintering technique (PM), such drills combine the advantages of conventional
Cobalt HSS-E and solid carbid drills, resulting cheaper and less subject to breakage. FIRE-coated
surface, for high-speed working, dry working, or when using nebulized lubrication-cooler.
For high-percentage alloy steel, quenched and tempered steel and case hardening steel, cast
iron, brass and bronze.
Cylindrical shank according to DIN 1835A. FIRE treatment.
Ø
mm
2
2,5
3
3,3 3,5
4
4,2 4,5
5
5,5
6
6,5*
6,8
7
7,5
Overall length
mm 56
62
65
68
71
75
87
91
96 101 101 107 113 113 113
Helix length
mm 24
30
33
36
39
43
43
47
52
57
57
63
69
69
69
Drive Ø
mm 3
3
3
4
4
4
6
6
6
6
6
8
8
8
8
Drive length
mm 28
28
28
28
28
28
36
36
36
36
36
36
36
36
36
8464G
Each 23,10 27,30 27,30 30,40 30,40 33,60 41,40 39,70 50,10 50,10 54,30 62,10 70,70 70,70 72,40
Ø
mm
8
8,5
9
9,5*
10 10,2* 10,5*
11 11,5 12 13*
Overall length
mm 119 125 131 131 137 144 144 151 151 158 161
Helix length
mm 75
75
81
81
87
87
87
94
94 101 101
Drive Ø
mm 8
10
10
10
10
12
12
12
12
12
14
Drive length
mm 36
40
40
40
40
45
45
45
45
45
48
8464G
Each 76,70 86,20 77,60 83,60 91,30 107,00 114,00 107,00 114,00 125,00 164,00
* Sizes running out of stock.
DRILLSFORMETALS,RIGHT-HANDROTATION
CARBIDE TIPPED TWIST DRILLS, RIGHT-HAND ROTATION
8465G
HARTMETALL
Prod. SCU
Similar to DIN 338. SUPER RAPID HSS body, with HARD METAL cutting edges (only sizes 2 and
2,5 mm in integral HARD METAL).
SHORT pattern. Cutting angle 120°.
For manganese steel, nickel, cast iron, bronze, brass, aluminium, bakelite, etc. with resistance
ranging from R 700N/sqmm to R 2300 N/sqmm.
Cylindrical shank.
Ø
mm
2
2,1*
2,5 2,6*
3
3,1 3,2 3,3 3,5 3,6 3,9*
4
4,2 4,3 4,4*
Overall length
mm 51
49
57
57
61
70
70
70
70
75
75
75
80
80
80
Helix length
mm 24
24
30
30
33
39
39
39
39
43
43
43
47
47
47
8465G
Each 12,90 10,40 12,90 10,40 12,60 12,60 12,60 12,60 12,60 11,60 9,98 11,60 12,10 12,10 10,40
Ø
mm
4,5 4,6*
5
5,1 5,2 5,3 5,5 5,6*
5,7*
5,8
6
6,5 6,7 6,8 6,9*
Overall length
mm 80
80
86
93
93
93
93
93
93
93
93 101 109 109 109
Helix length
mm 47
47
52
57
57
57
57
57
57
57
57
63
69
69
69
8465G
Each 12,10 10,70 12,60 13,20 13,20 13,20 13,20 11,60 11,60 13,70 14,40 14,40 15,30 15,30 13,20
Ø
mm
7
7,1 7,5 7,9*
8
8,1*
8,5 8,6*
8,9*
9
9,1*
9,2*
9,3*
9,4*
9,5
Overall length
mm 109 109 109 117 117 117 117 125 125 125 125 125 125 125 125
Helix length
mm 69
69
69
75
75
75
75
81
81
81
81
81
81
81
81
8465G
Each 15,30 16,50 16,50 15,10 17,70 16,30 19,30 17,40 17,20 20,50 18,50 18,50 18,50 18,50 21,90
Ø
mm
9,6*
9,7*
10 10,5 12 12,5 13 13,5 14
15
16
Overall length
mm 133 133 133 133 151 151 151 160 160 169 178
Helix length
mm 87
87
87
87 101 101 101 108 108 114 120
8465G
Each 19,80 20,10 23,70 27,10 34,10 37,50 38,10 62,30 67,90 75,90 87,10
* Sizes running out of stock.
vuoto
CARBIDETIPPEDTWISTDRILLS,RIGHT-HANDROTATION
