1147 / 1378
1147
MULTIPLEX INTERCHANGEABLE BLADES
1147
13
Prices in EURO - VAT not included
8630GTF
HSS-E
FIRE
Orig. Hartner - Art. 86608
Suitable for drilling high-resistance and difficult to chip steel.
RIGHT-HAND rotation. Supplied without screws.
COBALT HSS-E, FIRE coating (special Titanium Nitride and Aluminium multilayer coating).
Cutting angle 135°.
Ø
mm
10
12
13 13,5 14 14,25 14,5 15 15,5 16 16,5 17 17,5 18 18,25
Thickness
mm 2,5 2,5 2,5 3,5 3,5 3,5 3,5 3,5 3,5 3,5 3,5 3,5 3,5 3,5 3,5
8630GTF
Each 56,10 56,10 56,10 66,80 66,80 66,80 66,80 66,80 66,80 66,80 66,80 66,80 66,80 66,80 66,80
Ø
mm
18,5 18,75 19
20 20,5 21
22 22,5 23 23,5 24 24,5 25
Thickness
mm 3,5 3,5
4
4
4
4
4
4
4
4
4
4
4
8630GTF
Each 66,80 66,80 81,30 81,30 81,30 81,30 81,30 81,30 81,30 81,30 81,30 81,30 81,30
Tool bits Art. 8630 GTF suitable for tool bit holder Art. 8625 G/8625 GL/8625 GP/8628 G/8628 GL/8629 G/8629 GL Size 1 to Size 6.
vuoto
MULTIPLEX INTERCHANGEABLEBLADES
8630GV
HSS-E
AITiN
Orig. Hartner - Art. 86609
Suitable for drilling high-resistance steel, stainless steel, cast iron, heat-resistance alloys,
aluminium, non-ferrous alloys.
RIGHT-HAND rotation. Supplied without screws.
From 25mm to 65mm, HSS-E PM sinterized (ASP 2052) cutting angle 132°. From 68mm to
102mm, HSS-E standard, cutting angle 140°.
All sizes with new AlTiN coating, changed and improved, with V-shaped chip-breaker and beveled
edge, for large use, longer life, reduced possibility of breakage of the tool bit, better finishing of
holes and higher working parameters.
Ø
mm
25 25,5 26 26,5 27
28
29 29,5 30
31
32
33
34
35
36
Thickness
mm 5
5
5
5
5
5
5
5
5
5
5
5
5
5
7
8630GV
Each 99,60 99,60 99,60 99,60 99,60 99,60 99,60 102,00 102,00 102,00 102,00 102,00 102,00 102,00 118,00
Ø
mm
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
Thickness
mm 7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
8630GV
Each 118,00 118,00 118,00 118,00 118,00 118,00 118,00 118,00 118,00 138,00 138,00 138,00 138,00 138,00 138,00
Ø
mm
52
53
54
55
56
57
58
59
60
62
64
65
68
70
74
Thickness
mm 7
7
7
7
7
7
7
7
7
7
7
7
9
9
9
8630GV
Each 138,00 138,00 138,00 138,00 149,00 149,00 149,00 149,00 149,00 149,00 149,00 149,00 187,00 187,00 187,00
Ø
mm
75
80
82
84
85
88
90 100 102
Thickness
mm 9
9
9
9
9
9
9
9
9
8630GV
Each 187,00 219,00 219,00 201,00 219,00 219,00 219,00 252,00 252,00
Tool bits Art. 8630 GV 25 to 65mm suitable for tool bit holder Art. 8625 G/8625 GL/8625 GP Size 7 to 11 and Art. 8627 G/8627 GL Size 1 to 5.
Tool bits Art 8630GV from 68mm to 102mm are suitable for tool bit holder Art. 8627 G/8627 GL from Gr. 6 to Gr.8.
Size mm 84 running out of stock.
vuoto
MULTIPLEX INTERCHANGEABLEBLADES
8631A
HARTMETALL
TIN
Orig. Hartner
HARDMETAL (HM), TIN coating. For high-speed working with nebulized lubrication-cooler.
RIGHT-HAND rotation. Supplied without screws.
Non-chamfered type, suitable for drilling materials with resistance up to 600 N/mmq.
Ø
mm
10 10,5 12 13,5 14,5 15
17 17,5
Thickness
mm 2,5
2,5
2,5
3,5
3,5
3,5
3,5
3,5
8631A
Each 76,30 76,30 76,30 103,00 103,00 103,00 103,00 103,00
Ø
mm
18 18,5 19
20
22 22,5 23 23,5
Thickness
mm 3,5
3,5
4
4
4
4
4
4
8631A
Each 103,00 103,00 127,00 127,00 127,00 127,00 127,00 127,00
Ø
mm
24
25
Thickness
mm 4
4
8631A
Each 127,00 127,00
vuoto
Tool bits Art. 8631 A suitable for tool bit holder Art. 8625 G/8625 GL/8625 GP/8628 G/8628 GL/8629 G/8629 GL Size 1 to Size 6.
Product running out of stock.
