MULTIPLEX INTERCHANGEABLE BLADES
1149
13
Prices in EURO - VAT not included
8633G
HARTMETALL
FIRE
Orig. Hartner - Art. 86702
Product description as Art. 8631G
Non-chamfered, suitable for drilling materials with resistance up to 600N/sqmm.
Ø
mm
10 10,5 11
12 12,5 13 13,5 14
Thickness
mm 2,5
2,5
2,5
2,5
2,5
2,5
3,5
3,5
8633G
Each 90,30 90,30 90,30 90,30 90,30 90,30 120,00 120,00
Ø
mm
14,5 15 15,5 16,5 17 17,5 18 18,5
Thickness
mm 3,5
3,5
3,5
3,5
3,5
3,5
3,5
3,5
8633G
Each 120,00 120,00 120,00 120,00 120,00 120,00 120,00 120,00
Ø
mm
19 19,5 20 20,5 21 21,5 22
23
Thickness
mm 4
4
4
4
4
4
4
4
8633G
Each 150,00 150,00 150,00 150,00 150,00 150,00 150,00 150,00
Ø
mm
25
26
27
28
29
30
33
34
Thickness
mm 4
5
5
5
5
5
5
5
8633G
Each 150,00 181,00 181,00 181,00 181,00 192,00 192,00 192,00
Ø
mm
35
Thickness
mm 5
8633G
Each 192,00
Tool bits Art.8633 G up to 25mm suitable for tool bit holder Art. 8625 G/8625 GL/8625 GP/8628 G/8628 GL/8629 G/8629 GL Size 1 to 6.
Tool bits Art. 8633 G 26 to 35mm suitable for tool bit holder Art. 8625 G/8625 GL/8625 GP Size 7-8, Art. 8627 G/8627 GL Size 1-2.
vuoto
MULTIPLEX INTERCHANGEABLEBLADES
ACCESSORIES FOR COOLANT FEED, MULTIPLEX SYSTEM
8637GA
Orig. Hartner
CHUCKS WITH INTERNAL/EXTERNAL MORSE TAPER SHANK
Made of steel, very high precision, for max hole centring.
Suitable for tool bit holder Art. 8629G/8629 GL and drills Art. 8526 G.
Max use pressure 16 bars.
Ext./Int. Morse cone
C.M.
2/2
Overall length (l1)
mm 165
Length without C.M (l2)
mm 90
Ø (D)
mm 75
8637GA
Each on request
Product running out of stock.
ACCESSORIESFORCOOLANTFEED,MULTIPLEXSYSTEM
8637GE
CHUCKS WITH EXTERNAL SHANK DIN 2080A AND INTERNAL MORSE TAPER SHANK
Made of steel, very high precision, for max hole centring.
Suitable for tool bit holder Art. 8629G/8629 GL and drills Art. 8526 G.
Max use pressure 16 bars.
Ext SK cone / int. C.M.
50/2
Overall length (l1)
mm 258
Length without SK (l2)
mm 146
Ø (D)
mm 112
8637GE
Each on request
Product running out of stock.
ACCESSORIESFORCOOLANTFEED,MULTIPLEXSYSTEM
8637GM
CHUCKS WITH EXTERNAL CONICAL SHANK AND INTERNAL CYLINDRICAL SHANK
Made of steel, very high precision, for max hole centring.
Suitable for tool bit holder Art. 8625 G/8625 GL/8625 GP Size 1 to 6.
Max use pressure 16 bars.
Ext cone / int. cyl.
SK 50-20
Dimensions d
mm 20
Dimensions L
mm 105
Dimensions D
mm 50
Dimensions D1
mm 78
Dimensions H
mm 50
Dimensions L1
mm 20
Dimensions L2
mm -
Dimensions 2-B
12
CM
M.
24
8637GM
Each on request
Other types of chucks for liquid coolant adduction.
Product running out of stock.
